FLIR M364C 30hz High Resolution Marine Thermal Camera NEW (M364C)
FLIR M364C 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt, 2-axis gyro stabilization and ultra low-light visible sensor.
Multispectral Marine Cameras with Active Gyro-Stabilization
Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision™, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene.
2-Axis Stabilization
Mechanical image stabilization provides a steady view in rough seas.
Color Thermal Vision
Blends the visible camera with a thermal image for positive identification of buoys and other vessels.
Two Camera Payloads
High Resolution Thermal Ultra Low Light Visible Camera.
Elite Awareness with Multispectral Imaging
Thermal imaging detects objects in complete darkness, glare, and light fog
Marine Video Analytics (MVA) object detection technology recognizes and highlights non-water objects like boats, buoys, or floating debris
Color Thermal Vision blends the thermal and low light visible cameras to easily identify color details like navigational lights and navigation aids.
Superior FLIR Thermal and Ultra-Low Light Night Vision
The M364C and M364C LR - our most advanced M300 series cameras
FLIR Boson thermal imaging core combined with HD visible camera
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and two independent IP video stream for expanded integration.
Specifications :
Thermal Camera
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
M364C - 24 ° x 18 °
Focal Length
M364C - 18mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
Visible Camera
Detector Type
1/2.8” CMOS
Resolution
Up to 1920 x 1080 @ 30fps
Minimum Illumination
Low Light Setting ON: 0.006 lux / Low Light Setting OFF: 0.1 lux
Optical Zoom
30x
Digital Zoom
12x
Focal Length
129 mm to 4.3 mm
Field of View
63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
System
Gyro Stabilized
Yes. 2-Axis.
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Color Thermal Vision
Yes
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
2 HD H.264 Main Streams, 2 H.264 Sub Streams, 1 Live Stream
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24 VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13 Degree F to 131Degree F (-25°C to 55°C)
Storage Temperature Range
-30 Degree F to 158 Degree F (-30 Degree C to 70 Degree C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike up to 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
M364C - 3.2nm (5.92km)
NATO Target 2.3m x 2.3m @50%
M364C - 0.95nm (1.76km)
Detect Human Sized Target
M364C - 0.39nm (725m)
Also you can check product : FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt, 2-axis gyro stabilization and ultra low-light visible sensor.
Multispectral Marine Cameras with Active Gyro-Stabilization
Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision™, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene.
2-Axis Stabilization
Mechanical image stabilization provides a steady view in rough seas.
Color Thermal Vision
Blends the visible camera with a thermal image for positive identification of buoys and other vessels.
Two Camera Payloads
High Resolution Thermal Ultra Low Light Visible Camera.
Elite Awareness with Multispectral Imaging
Thermal imaging detects objects in complete darkness, glare, and light fog
Marine Video Analytics (MVA) object detection technology recognizes and highlights non-water objects like boats, buoys, or floating debris
Color Thermal Vision blends the thermal and low light visible cameras to easily identify color details like navigational lights and navigation aids.
Superior FLIR Thermal and Ultra-Low Light Night Vision
The M364C and M364C LR - our most advanced M300 series cameras
FLIR Boson thermal imaging core combined with HD visible camera
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and two independent IP video stream for expanded integration.
Specifications :
Thermal Camera
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
M364C - 24 ° x 18 °
Focal Length
M364C - 18mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
Visible Camera
Detector Type
1/2.8” CMOS
Resolution
Up to 1920 x 1080 @ 30fps
Minimum Illumination
Low Light Setting ON: 0.006 lux / Low Light Setting OFF: 0.1 lux
Optical Zoom
30x
Digital Zoom
12x
Focal Length
129 mm to 4.3 mm
Field of View
63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
System
Gyro Stabilized
Yes. 2-Axis.
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Color Thermal Vision
Yes
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
2 HD H.264 Main Streams, 2 H.264 Sub Streams, 1 Live Stream
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24 VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13 Degree F to 131Degree F (-25°C to 55°C)
Storage Temperature Range
-30 Degree F to 158 Degree F (-30 Degree C to 70 Degree C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike up to 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
M364C - 3.2nm (5.92km)
NATO Target 2.3m x 2.3m @50%
M364C - 0.95nm (1.76km)
Detect Human Sized Target
M364C - 0.39nm (725m)
Also you can check product : FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW
Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision™, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene. This premium advanced maritime system features a high-definition low-light camera and one of the most cutting-edge FLIR thermal imaging cores. The MC36C provides exceptional situational awareness on the water, utilizing multispectral imaging to deliver exclusive FLIR Color Thermal Vision (CTV) technology.
FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW (M364C LR)
FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt, 2-axis gyro stabilization and ultra low-light visible sensor.
Multispectral Marine Cameras with Active Gyro-Stabilization
Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision™, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene.
2-Axis Stabilization
Mechanical image stabilization provides a steady view in rough seas.
Color Thermal Vision
Blends the visible camera with a thermal image for positive identification of buoys and other vessels.
Two Camera Payloads
High Resolution Thermal Ultra Low Light Visible Camera.
Elite Awareness with Multispectral Imaging
Thermal imaging detects objects in complete darkness, glare, and light fog
Marine Video Analytics (MVA) object detection technology recognizes and highlights non-water objects like boats, buoys, or floating debris
Color Thermal Vision blends the thermal and low light visible cameras to easily identify color details like navigational lights and navigation aids.
Superior FLIR Thermal and Ultra-Low Light Night Vision
The M364C and M364C LR — our most advanced M300 series cameras
FLIR Boson thermal imaging core combined with HD visible camera
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and two independent IP video stream for expanded integration.
Specifications :
Thermal Camera
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
M364C LR - 18 Degree x 13.5 Degree
Focal Length
M364C LR - 25mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
Visible Camera
Detector Type
1/2.8” CMOS
Resolution
Up to 1920 x 1080 @ 30fps
Minimum Illumination
Low Light Setting ON: 0.006 lux / Low Light Setting OFF: 0.1 lux
Optical Zoom
30x
Digital Zoom
12x
Focal Length
129 mm to 4.3 mm
Field of View
63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
System
Gyro Stabilized
Yes. 2-Axis.
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Color Thermal Vision
Yes
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
2 HD H.264 Main Streams, 2 H.264 Sub Streams, 1 Live Stream
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24 VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13°F to 131°F (-25°C to 55°C)
Storage Temperature Range
-30°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike up to 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
M364C LR - 4.26nm (7.89km)
NATO Target 2.3m x 2.3m @50%
M364C LR - 1.26nm (2.34km)
Detect Human Sized Target
M364C LR - 0.52nm (966m)
Also you can check product : FLIR M364C 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt, 2-axis gyro stabilization and ultra low-light visible sensor.
Multispectral Marine Cameras with Active Gyro-Stabilization
Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision™, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene.
2-Axis Stabilization
Mechanical image stabilization provides a steady view in rough seas.
Color Thermal Vision
Blends the visible camera with a thermal image for positive identification of buoys and other vessels.
Two Camera Payloads
High Resolution Thermal Ultra Low Light Visible Camera.
Elite Awareness with Multispectral Imaging
Thermal imaging detects objects in complete darkness, glare, and light fog
Marine Video Analytics (MVA) object detection technology recognizes and highlights non-water objects like boats, buoys, or floating debris
Color Thermal Vision blends the thermal and low light visible cameras to easily identify color details like navigational lights and navigation aids.
Superior FLIR Thermal and Ultra-Low Light Night Vision
The M364C and M364C LR — our most advanced M300 series cameras
FLIR Boson thermal imaging core combined with HD visible camera
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and two independent IP video stream for expanded integration.
Specifications :
Thermal Camera
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
M364C LR - 18 Degree x 13.5 Degree
Focal Length
M364C LR - 25mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
Visible Camera
Detector Type
1/2.8” CMOS
Resolution
Up to 1920 x 1080 @ 30fps
Minimum Illumination
Low Light Setting ON: 0.006 lux / Low Light Setting OFF: 0.1 lux
Optical Zoom
30x
Digital Zoom
12x
Focal Length
129 mm to 4.3 mm
Field of View
63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
System
Gyro Stabilized
Yes. 2-Axis.
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Color Thermal Vision
Yes
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
2 HD H.264 Main Streams, 2 H.264 Sub Streams, 1 Live Stream
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24 VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13°F to 131°F (-25°C to 55°C)
Storage Temperature Range
-30°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike up to 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
M364C LR - 4.26nm (7.89km)
NATO Target 2.3m x 2.3m @50%
M364C LR - 1.26nm (2.34km)
Detect Human Sized Target
M364C LR - 0.52nm (966m)
Also you can check product : FLIR M364C 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt, 2-axis gyro stabilization and ultra low-light visible sensor. Featuring a high definition ultra-low light camera and one of the most advanced FLIR thermal imaging cores, the M364C and M364C LR provide an elite level of awareness on the water. Both models feature use multispectral FLIR Color Thermal Vision, the blending of the visible camera with thermal to let mariners use color enhanced imagery to identify navigation aids and other vessels within the thermal scene
FLIR M364 30hz High Resolution Marine Thermal Camera NEW (M364)
FLIR M364 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization.
Marine Thermal Camera with Active Gyro-Stabilization
The M364 combines a robust, all-weather design with a leading edge high resolution FLIR thermal senso, providing enhanced situational awareness for maritime professionals and recreational boaters. Its advanced gyro-stabilization and high-resolution thermal sensor make it possible to detect obstacles and targets even in total darkness and rough seas, ensuring safe navigation under the most demanding conditions.
Pan and Tilt
Navigate safer and explore with 360° pan and /-90° tilt capability. Control the M332 with your chartplotter or optional joystick control unit.
2-Axis Stabilization
Navigate with a steady view in rough seas. Vertical stabilization compensates for vessel pitch and horizontal stabilization maintains the M364's field of view on a selected bearing.
High Resolution
A high resolution 640x512 FLIR thermal sensor delivers superior night vision and almost twice the range capability as a standard thermal sensor.
Superior FLIR Thermal Night Vision
The FLIR M364 offers night vision in complete darkness, glare, and light fog.
Powered by the breakthrough FLIR Boson thermal imaging core
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and IP video for expanded integration
Marine Video Analytics intelligently identifies non-water objects.
Chartplotter Compatible
FLIR M-Series cameras are designed to integrate seamlessly with chartplotters and multi-function display from Furuno, Garmin, Raymarine and Simrad. View the thermal image on your chartplotter display and control the camera's pan and tilt with your chartplotter's touchscreen.
Specifications :
General
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
24 Degree x 18 Degree
Focal Length
18 mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
System
Gyro Stabilized
Yes
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
Two, Independent H.264/MJPEG Network Video Streams
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13°F to 131°F (-25°C to 55°C)
Storage Temperature Range
-22°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike at 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg)
Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm)
Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
3.2nm (5.92km)
NATO Target 2.3m x 2.3m @50%
0.95nm (1.76km)
Detect Human Sized Target
0.39nm (725m)
Also you can check product : FLIR M364C 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization.
Marine Thermal Camera with Active Gyro-Stabilization
The M364 combines a robust, all-weather design with a leading edge high resolution FLIR thermal senso, providing enhanced situational awareness for maritime professionals and recreational boaters. Its advanced gyro-stabilization and high-resolution thermal sensor make it possible to detect obstacles and targets even in total darkness and rough seas, ensuring safe navigation under the most demanding conditions.
Pan and Tilt
Navigate safer and explore with 360° pan and /-90° tilt capability. Control the M332 with your chartplotter or optional joystick control unit.
2-Axis Stabilization
Navigate with a steady view in rough seas. Vertical stabilization compensates for vessel pitch and horizontal stabilization maintains the M364's field of view on a selected bearing.
High Resolution
A high resolution 640x512 FLIR thermal sensor delivers superior night vision and almost twice the range capability as a standard thermal sensor.
Superior FLIR Thermal Night Vision
The FLIR M364 offers night vision in complete darkness, glare, and light fog.
Powered by the breakthrough FLIR Boson thermal imaging core
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and IP video for expanded integration
Marine Video Analytics intelligently identifies non-water objects.
Chartplotter Compatible
FLIR M-Series cameras are designed to integrate seamlessly with chartplotters and multi-function display from Furuno, Garmin, Raymarine and Simrad. View the thermal image on your chartplotter display and control the camera's pan and tilt with your chartplotter's touchscreen.
Specifications :
General
Detector Type
640x512 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
24 Degree x 18 Degree
Focal Length
18 mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
System
Gyro Stabilized
Yes
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
Two, Independent H.264/MJPEG Network Video Streams
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13°F to 131°F (-25°C to 55°C)
Storage Temperature Range
-22°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike at 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg)
Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm)
Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
3.2nm (5.92km)
NATO Target 2.3m x 2.3m @50%
0.95nm (1.76km)
Detect Human Sized Target
0.39nm (725m)
Also you can check product : FLIR M364C 30hz High Resolution Marine Thermal Camera NEW
High resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization. The M364 combines a robust, all-weather design with a leading edge high resolution FLIR thermal senso, providing enhanced situational awareness for maritime professionals and recreational boaters. Its advanced gyro-stabilization and high-resolution thermal sensor make it possible to detect obstacles and targets even in total darkness and rough seas, ensuring safe navigation under the most demanding conditions.
FLIR M332 30hz Marine Thermal Camera NEW (M332)
FLIR M332 30hz Marine Thermal Camera NEW
Standard resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization.
Marine Thermal Camera with Active Gyro-Stabilization
Pairing a rugged, all-weather design with one of the most advanced FLIR thermal imaging cores, the M332 delivers awareness-enhancing thermal vision for law enforcement, commercial, and recreational boaters. Advanced gyro-stabilization and a standard resolution thermal sensor detects obstacles and targets in complete darkness and heavy seas, allowing safe navigation in the most challenging conditions.
Pan and Tilt
Navigate safer and explore with 360 Degree pan and /-90 Degree tilt capability. Control the M332 with your chartplotter or optional joystick control unit.
2-Axis Stabilization
Navigate with a steady view in rough seas. Vertical stabilization compensates for vessel pitch and horizontal stabilization maintains the M332's field of view on a selected bearing.
Standard Resolution
A 320x240 FLIR thermal sensor detects changes in heat so you can see boats and buoys in total darkness.
Safe Navigation in Low Visibility Environments
Thermal night vision offers vision in complete darkness, glare, and light fog.
Powered by the breakthrough FLIR Boson thermal imaging core
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and IP video for expanded integration
Marine Video Analytics intelligently identifies non-water objects.
Chartplotter Compatible
FLIR M-Series cameras are designed to integrate seamlessly with chartplotters and multi-function display from Furuno, Garmin, Raymarine and Simrad. View the thermal image on your chartplotter display and control the camera's pan and tilt with your chartplotter's touchscreen.
Specifications :
General
Detector Type
320x256 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
24 ° x 18 °
Focal Length
9.1mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
System
Gyro Stabilized
Yes
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
Two, Independent H.264/MJPEG Network Video Streams
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13 Degree F to 131DegreeF (-25 Degree C to 55 Degree C)
Storage Temperature Range
-22°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike at 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg)
Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm)
Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
1.60nm (2.96km)
NATO Target 2.3m x 2.3m @50%
0.47nm (879m)
Detect Human Sized Target
0.20nm (362m)
Also you can check product : FLIR M364 30hz High Resolution Marine Thermal Camera NEW
Standard resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization.
Marine Thermal Camera with Active Gyro-Stabilization
Pairing a rugged, all-weather design with one of the most advanced FLIR thermal imaging cores, the M332 delivers awareness-enhancing thermal vision for law enforcement, commercial, and recreational boaters. Advanced gyro-stabilization and a standard resolution thermal sensor detects obstacles and targets in complete darkness and heavy seas, allowing safe navigation in the most challenging conditions.
Pan and Tilt
Navigate safer and explore with 360 Degree pan and /-90 Degree tilt capability. Control the M332 with your chartplotter or optional joystick control unit.
2-Axis Stabilization
Navigate with a steady view in rough seas. Vertical stabilization compensates for vessel pitch and horizontal stabilization maintains the M332's field of view on a selected bearing.
Standard Resolution
A 320x240 FLIR thermal sensor detects changes in heat so you can see boats and buoys in total darkness.
Safe Navigation in Low Visibility Environments
Thermal night vision offers vision in complete darkness, glare, and light fog.
Powered by the breakthrough FLIR Boson thermal imaging core
Rugged IPX6 pan and tilt housing is built to withstand the elements
Advanced onboard image processing technology
Analog video, HD-SDI, and IP video for expanded integration
Marine Video Analytics intelligently identifies non-water objects.
Chartplotter Compatible
FLIR M-Series cameras are designed to integrate seamlessly with chartplotters and multi-function display from Furuno, Garmin, Raymarine and Simrad. View the thermal image on your chartplotter display and control the camera's pan and tilt with your chartplotter's touchscreen.
Specifications :
General
Detector Type
320x256 VOx Microbolometer
Video Refresh Rate
30 Hz or <9 Hz
Field of View
24 ° x 18 °
Focal Length
9.1mm
Focus
Fixed 12 ft (3m) to infinity
Optical Zoom
N/A
Digital Zoom
4x Continuous
System
Gyro Stabilized
Yes
Marine Video Analytics (MVA)
Yes
Pan/Tilt Adjustment Range
360° Continuous Pan, /- 90° Tilt
Analog Video Output
NTSC/PAL User Settable
Analog Video Connector Types
BNC
Network Video Output
Two, Independent H.264/MJPEG Network Video Streams
HD-SDI Lossless Video Output
Yes
Power Requirements
12 to 24VDC
Power Consumption
41W nominal; 56W w/ heaters
ONVIF
Profile S Conformance
Environmental
Operating Temperature Range
-13 Degree F to 131DegreeF (-25 Degree C to 55 Degree C)
Storage Temperature Range
-22°F to 158°F (-30°C to 70°C)
Automatic Window Defrost
Standard at Power-Up
Water Ingress
IPX6
Shock
15g vertical, 9g horizontal
Vibration
IEC60945
Lightning Protection
Near Strike at 2kV
Salt Mist
IEC60945
EMI
IEC60945
Physical
Weight
Camera: 13.9lbs (6.3kg)
Camera with Top-Down Riser: 14.9lbs (6.8kg)
Size
Camera: 8.7” (222mm) x 12.9” (328mm)
Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Range
Detect a 30-foot Vessel
1.60nm (2.96km)
NATO Target 2.3m x 2.3m @50%
0.47nm (879m)
Detect Human Sized Target
0.20nm (362m)
Also you can check product : FLIR M364 30hz High Resolution Marine Thermal Camera NEW
Standard resolution marine thermal camera with pan and tilt and 2-axis gyro stabilization. Pairing a rugged, all-weather design with one of the most advanced FLIR thermal imaging cores, the M332 delivers awareness- enhancing thermal vision for law enforcement, commercial, and recreational boaters. Advanced gyro-stabilization and a standard resolution thermal sensor detects obstacles and targets in complete darkness and heavy seas, allowing safe navigation in the most challenging conditions.
FLIR MD-625 Static Thermal Night Vision Camera with Joystick Control NEW (MD-625)
FLIR MD-625 Static Thermal Night Vision Camera with Joystick Control NEW
The MD-Series is an affordable, compact fixed-mounted thermal night vision system that helps with steering around obstacles, collision avoidance, and finding people in the water at night. Simple to mount and easy to integrate into your existing electronics, MD-Series outputs standard analog video that can be easily displayed on almost any monitor at the helm or other locations on the vessel.
DISPLAYS HEAT, NOT LIGHT
The MD625’s 640 x 480 resolution thermal sensor reveals vessels and obstacles in total darkness and even midday glare.
SIMPLE TO MOUNT
A compact, all weather, water proof enclosure provides easy mounting.
ETHERNET-ENABLED
The MD625 is Ethernet-enabled for simple integration into your vessel’s existing electronics.
Specifications :
Detector Type
640 x 480 VOx Microbolometer
FOV
25° x 20° (NTSC)
Focal Length
25 mm
E-zoom
2x, 4x
Image Processing
FLIR Proprietary Digital Detail Enhancement
Size
6" dia. x 7" ht
Weight
3 lbs
Pan/Tilt Coverage
Pan: ±30° per key
Tilt
34°, -27° (Locked in at Installation), 30 Hz or <9Hz>
Connector Types
F-type
Power Requirements
PoE injector required per IEEE 802.3af
Power Consumption
4.8 W nominal; 12.5 W max
Operating Temperature Range
-25°C to 55°C
Sand/Dust
Mil-Std-810E
Water Ingress
IPX6
Shock
15 g vertical, 9 g horizontal
Vibration
IEC 60945; MIL-STD-810E
Lightening Protection
Standard
Salt Mist
IEC60945
Wind
100 knot (115.2 mph)
EMI
IEC 60945
INCLUDED :
Camera Head with -5" of Cable Analog Video, and Ethernet (PoE powered device)
BNC with BNC-to-RCA adapter for video out
Operator Manual CD
Joystick Control Unit
Also you can check product : FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW
The MD-Series is an affordable, compact fixed-mounted thermal night vision system that helps with steering around obstacles, collision avoidance, and finding people in the water at night. Simple to mount and easy to integrate into your existing electronics, MD-Series outputs standard analog video that can be easily displayed on almost any monitor at the helm or other locations on the vessel.
DISPLAYS HEAT, NOT LIGHT
The MD625’s 640 x 480 resolution thermal sensor reveals vessels and obstacles in total darkness and even midday glare.
SIMPLE TO MOUNT
A compact, all weather, water proof enclosure provides easy mounting.
ETHERNET-ENABLED
The MD625 is Ethernet-enabled for simple integration into your vessel’s existing electronics.
Specifications :
Detector Type
640 x 480 VOx Microbolometer
FOV
25° x 20° (NTSC)
Focal Length
25 mm
E-zoom
2x, 4x
Image Processing
FLIR Proprietary Digital Detail Enhancement
Size
6" dia. x 7" ht
Weight
3 lbs
Pan/Tilt Coverage
Pan: ±30° per key
Tilt
34°, -27° (Locked in at Installation), 30 Hz or <9Hz>
Connector Types
F-type
Power Requirements
PoE injector required per IEEE 802.3af
Power Consumption
4.8 W nominal; 12.5 W max
Operating Temperature Range
-25°C to 55°C
Sand/Dust
Mil-Std-810E
Water Ingress
IPX6
Shock
15 g vertical, 9 g horizontal
Vibration
IEC 60945; MIL-STD-810E
Lightening Protection
Standard
Salt Mist
IEC60945
Wind
100 knot (115.2 mph)
EMI
IEC 60945
INCLUDED :
Camera Head with -5" of Cable Analog Video, and Ethernet (PoE powered device)
BNC with BNC-to-RCA adapter for video out
Operator Manual CD
Joystick Control Unit
Also you can check product : FLIR M364C LR 30hz High Resolution Marine Thermal Camera NEW
The MD-Series is an affordable, compact fixed-mounted thermal night vision system that helps with steering around obstacles, collision avoidance, and finding people in the water at night. Simple to mount and easy to integrate into your existing electronics, MD-Series outputs standard analog video that can be easily displayed on almost any monitor at the helm or other locations on the vessel. Use a single application to control all of your FLIR Thermal imaging, night vision, and infrared cameras from your iPad or iPhone. The app allows for intuitive control with natural gestures.
Raymarine Axiom 2 Pro S 16" Chartplotter/Fishfinders with Lighthouse Chart NEW (Axiom 2 Pro S)
Raymarine Axiom 2 Pro S 16" Chartplotter/Fishfinders with Lighthouse Chart NEW
A Trusted Crew Member
When cruising the open ocean, the only thing that’s predictable is the unexpected. But when you have tools that provide ultimate awareness at your side, you’ll be ready for whatever nature throws at you.
Axiom 2 Pro S combines chartplotter, sonar, radar, autopilot and video into a powerful all-in-one navigation system. Plan your next cruise and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Use Axiom 2 Pro as a single GPS chartplotter or create a network of multiple Axiom displays with a simple RayNet cable connection. More than just a chartplotter, Axiom 2 Pro S features an integrated high CHIRP sonar, the ideal sonar for reliable depth soundings and underwater discovery.
Power That Pushes the Limits
Get underway quickly with Axiom 2 Pro’s powerful 6-core processor. Enjoy faster, seamless integration of GPS, fishfinder, radar and video thanks to the super intuitive LightHouse operating system.
Ready for All Conditions
Axiom 2 Pro's HydroTough nano-coating technology repels water for reliable touchscreen control, enhanced colors and excellent sunlight visibility.
Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening lighting conditions.
Confident Control
Plan and plot your course with HybridTouch control and take command with reliable keypad control when seas are rough.
Customize your Axiom 2 Pro with interchangeable keypads that allow you to choose between a dedicated Evolution autopilot keypad or user-programable soft keys.
Advanced Sailing Tools
Axiom 2 Pro offers a suite of powerful features to help you optimize your performance under sail.
Polars and Dynamic Laylines
Axiom is preloaded with over 500 racing and cruising sailboat polar profiles. Load your polar profile and see how you measure up against your boat’s maximum potential. View real-time, dynamic laylines on your chart based on polars or fixed angles.
Race Like a Pro
Adjustable race timers, data dashboards, and a SmartStart™ starting line tool help you anticipate and visualize the start of your race. See line bias, time to burn as well as the favored end. Cross the line on time, at maximum power.
Tactical Advantage
Sailing and tactical-specific dial indicators let you see the direction to steer at a glance to maximize your boat’s Velocity Made Good (VMG) to windward. Trimming sails for optimum performance is now easier than ever.
One Display-Endless Possibilities
Discover More
Created from official hydrographic chart sources, you can trust LightHouse Charts for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 Pro turn night into day, keeping you safe and secure so you can boat with confidence.
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 Pro on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 Pro on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 Pro with third-party apps from our marine technology partners.
Create a Powerful Navigation System
Two RayNet Ethernet ports and NMEA2000 give you the flexibility to create an Axiom 2 Pro system with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions (Trunnion mounted)
Axiom 2 Pro 16: Height: 281.20 mm (11.10 in), Width 482.50 mm (19.00 in), Depth (including cables): 233.4 mm (9.18 in)
Dimensions (Surface/Flush mounted)
Axiom 2 Pro 16: Height: 258 mm (10.16 in), Width: 452.02 mm (17.8 in), Depth (including cables): 240.4 mm (9.46 in)
Connections
Ethernet connection
2 RayNet (10/100/1,000 Mbits/s) ports
NMEA 2000 connection
DeviceNet connector
Wi-Fi
Multiband - 2.4GHz, and 5Ghz 802.11b/g/n
Bluetooth
v4.0
Accessory connection
USB Micro B
Internal storage
64GB Solid State
External storage
2 front mounted MicroSDXC card slots
Digital Video and Audio
HDMI Out Micro connector type D
Analog video connections
BNC Analog video input (on power cable)
Analog audio connections
RCA connectors via power cable
External GPS anternna
TNC connector
Power
Power consumption @ 12 V dc
Axiom Pro 16: 42.36 W
Power consumption @ 24 V dc
Axiom Pro 16: 40.8 W
Operating voltage range
8 V dc to 32 V dc
Nominal supply voltage
12 V dc / 24 V dc
Off current @ 12 V dc
11 mA (0.13 W)
Off current @ 24 V dc
18 mA (0.43 W)
LEN (NMEA 2000 Load Equivalency Number)
1
Current
5 A
Fuse rating
15 A
GPS (GNSS)
Position Accuracy
Without SBAS: ≤ 15 metres 95% of the time, With SBAS: ≤ 5 metres 95% of the time
Geodetic Datum
WGS-84 (alternatives can be selected on the MFD)
Satellite Differential Type (SBAS)
WAAS (United States), EGNOS (Europe), MSAS (Japan), GAGAN (India), QZSS (Japan)
Channels
Track up to 28 satellites simultaneously
Antenna
Internal - Ceramic chip mounted near top of unit
GNSS compatibility
GPS, Galileo, GLONASS, Beidou
Almanac Update
Automatic
Signal Acquisition
Automatic
Receiver IC Sensitivity
165 dBm (Tracking), 160 dBm (Acquisition), 148 dBm (Cold start)
Operating frequency
1574 MHz to 1605 MHz
Refresh rate
10 Hz (10 times per second)
Time to first fix from cold start
< 2 minutes
Environmental
Operating temperature
-25°C to 55°C (-13°F to 131°F)
Storage temperature
-30°C to 70°C (-22°F to 158°F)
Relative humidity
Up to 93% @ 40°C (104°F)
Waterproof rating
IPx6, IPx7
LCD
Size (diagonal)
Axiom 2 Pro 16: 15.6"
Ratio
Axiom 2 Pro 16: 16:10
Resolution
Axiom 2 Pro 16: 1920 x 1080 FHD
Viewing angle
Top 88° / Bottom 88° / Left 88° / Right 88°
Type
IPS (In-Plane Switching)
Color depth
24-bit
Illumination
Axiom 2 Pro 16 1200 nits / 1200 cd/m2
Number of simultaneous touches
1 to 16
Sonar
Channels
CHIRP conical sonar
Depth range
0.6 m (2 ft) to 274 m (900 ft) Depending on water conditions
Transducer connection
25 pin RealVision type connector. Requires the A80490 adaptor cable for CPT-S style transducers
INCLUDED :
Display unit
User Configurable Keypad
Suncover
Gasket
Trunnion knobs (x 2)
Trunnion bracket (Axiom 2 Pro 9 and 12 Only)
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Mounting fixings x4
Documentation
Power/Video/Audio cable 1.5 m (4.92 ft)
A Trusted Crew Member
When cruising the open ocean, the only thing that’s predictable is the unexpected. But when you have tools that provide ultimate awareness at your side, you’ll be ready for whatever nature throws at you.
Axiom 2 Pro S combines chartplotter, sonar, radar, autopilot and video into a powerful all-in-one navigation system. Plan your next cruise and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Use Axiom 2 Pro as a single GPS chartplotter or create a network of multiple Axiom displays with a simple RayNet cable connection. More than just a chartplotter, Axiom 2 Pro S features an integrated high CHIRP sonar, the ideal sonar for reliable depth soundings and underwater discovery.
Power That Pushes the Limits
Get underway quickly with Axiom 2 Pro’s powerful 6-core processor. Enjoy faster, seamless integration of GPS, fishfinder, radar and video thanks to the super intuitive LightHouse operating system.
Ready for All Conditions
Axiom 2 Pro's HydroTough nano-coating technology repels water for reliable touchscreen control, enhanced colors and excellent sunlight visibility.
Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening lighting conditions.
Confident Control
Plan and plot your course with HybridTouch control and take command with reliable keypad control when seas are rough.
Customize your Axiom 2 Pro with interchangeable keypads that allow you to choose between a dedicated Evolution autopilot keypad or user-programable soft keys.
Advanced Sailing Tools
Axiom 2 Pro offers a suite of powerful features to help you optimize your performance under sail.
Polars and Dynamic Laylines
Axiom is preloaded with over 500 racing and cruising sailboat polar profiles. Load your polar profile and see how you measure up against your boat’s maximum potential. View real-time, dynamic laylines on your chart based on polars or fixed angles.
Race Like a Pro
Adjustable race timers, data dashboards, and a SmartStart™ starting line tool help you anticipate and visualize the start of your race. See line bias, time to burn as well as the favored end. Cross the line on time, at maximum power.
Tactical Advantage
Sailing and tactical-specific dial indicators let you see the direction to steer at a glance to maximize your boat’s Velocity Made Good (VMG) to windward. Trimming sails for optimum performance is now easier than ever.
One Display-Endless Possibilities
Discover More
Created from official hydrographic chart sources, you can trust LightHouse Charts for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 Pro turn night into day, keeping you safe and secure so you can boat with confidence.
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 Pro on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 Pro on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 Pro with third-party apps from our marine technology partners.
Create a Powerful Navigation System
Two RayNet Ethernet ports and NMEA2000 give you the flexibility to create an Axiom 2 Pro system with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions (Trunnion mounted)
Axiom 2 Pro 16: Height: 281.20 mm (11.10 in), Width 482.50 mm (19.00 in), Depth (including cables): 233.4 mm (9.18 in)
Dimensions (Surface/Flush mounted)
Axiom 2 Pro 16: Height: 258 mm (10.16 in), Width: 452.02 mm (17.8 in), Depth (including cables): 240.4 mm (9.46 in)
Connections
Ethernet connection
2 RayNet (10/100/1,000 Mbits/s) ports
NMEA 2000 connection
DeviceNet connector
Wi-Fi
Multiband - 2.4GHz, and 5Ghz 802.11b/g/n
Bluetooth
v4.0
Accessory connection
USB Micro B
Internal storage
64GB Solid State
External storage
2 front mounted MicroSDXC card slots
Digital Video and Audio
HDMI Out Micro connector type D
Analog video connections
BNC Analog video input (on power cable)
Analog audio connections
RCA connectors via power cable
External GPS anternna
TNC connector
Power
Power consumption @ 12 V dc
Axiom Pro 16: 42.36 W
Power consumption @ 24 V dc
Axiom Pro 16: 40.8 W
Operating voltage range
8 V dc to 32 V dc
Nominal supply voltage
12 V dc / 24 V dc
Off current @ 12 V dc
11 mA (0.13 W)
Off current @ 24 V dc
18 mA (0.43 W)
LEN (NMEA 2000 Load Equivalency Number)
1
Current
5 A
Fuse rating
15 A
GPS (GNSS)
Position Accuracy
Without SBAS: ≤ 15 metres 95% of the time, With SBAS: ≤ 5 metres 95% of the time
Geodetic Datum
WGS-84 (alternatives can be selected on the MFD)
Satellite Differential Type (SBAS)
WAAS (United States), EGNOS (Europe), MSAS (Japan), GAGAN (India), QZSS (Japan)
Channels
Track up to 28 satellites simultaneously
Antenna
Internal - Ceramic chip mounted near top of unit
GNSS compatibility
GPS, Galileo, GLONASS, Beidou
Almanac Update
Automatic
Signal Acquisition
Automatic
Receiver IC Sensitivity
165 dBm (Tracking), 160 dBm (Acquisition), 148 dBm (Cold start)
Operating frequency
1574 MHz to 1605 MHz
Refresh rate
10 Hz (10 times per second)
Time to first fix from cold start
< 2 minutes
Environmental
Operating temperature
-25°C to 55°C (-13°F to 131°F)
Storage temperature
-30°C to 70°C (-22°F to 158°F)
Relative humidity
Up to 93% @ 40°C (104°F)
Waterproof rating
IPx6, IPx7
LCD
Size (diagonal)
Axiom 2 Pro 16: 15.6"
Ratio
Axiom 2 Pro 16: 16:10
Resolution
Axiom 2 Pro 16: 1920 x 1080 FHD
Viewing angle
Top 88° / Bottom 88° / Left 88° / Right 88°
Type
IPS (In-Plane Switching)
Color depth
24-bit
Illumination
Axiom 2 Pro 16 1200 nits / 1200 cd/m2
Number of simultaneous touches
1 to 16
Sonar
Channels
CHIRP conical sonar
Depth range
0.6 m (2 ft) to 274 m (900 ft) Depending on water conditions
Transducer connection
25 pin RealVision type connector. Requires the A80490 adaptor cable for CPT-S style transducers
INCLUDED :
Display unit
User Configurable Keypad
Suncover
Gasket
Trunnion knobs (x 2)
Trunnion bracket (Axiom 2 Pro 9 and 12 Only)
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Mounting fixings x4
Documentation
Power/Video/Audio cable 1.5 m (4.92 ft)
Axiom 2 Pro S combines chartplotter, sonar, radar, autopilot and video into a powerful all-in-one navigation system. Plan your next cruise and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Use Axiom 2 Pro as a single GPS chartplotter or create a network of multiple Axiom displays with a simple RayNet cable connection. More than just a chartplotter, Axiom 2 Pro S features an integrated high CHIRP sonar, the ideal sonar for reliable depth soundings and underwater discovery.
Raymarine Axiom 2 Pro RVM 16" Chartplotter/Fishfinders with Lighthouse Chart NEW (Axiom 2 Pro RVM)
Raymarine Axiom 2 Pro RVM 16" Chartplotter/Fishfinders with Lighthouse Chart NEW
Your Offshore Adventure Guide
No matter where the day takes you, you’ll be able to handle the unexpected in stride thanks to superior awareness at every turn.
Axiom 2 Pro combines chartplotter, fish finder, radar, autopilot and video into a powerful all-in-one fishing system. Plan your next offshore adventure and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Designed for discovering the deep, Axiom 2 Pro RVM chartplotters feature an integrated multi-channel fish finder with RealVision® MAX CHIRP sonar technology.
Power That Pushes the Limits
Get underway quickly with Axiom 2 Pro’s powerful 6-core processor. Enjoy faster, seamless integration of GPS, fishfinder, radar and video thanks to the super intuitive LightHouse operating system.
Ready for All Conditions
Axiom 2 Pro's HydroTough nano-coating technology repels water for reliable touchscreen control, enhanced colors and excellent sunlight visibility.
Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening lighting conditions.
Confident Control
Plan and plot your course with HybridTouch control and take command with reliable keypad control when seas are rough.
Customize your Axiom 2 Pro with interchangeable keypads that allow you to choose between a dedicated Evolution autopilot keypad or user-programable soft keys.
Find More Fish with RealVision MAX
RealVision MAX ups your fishfinding game with increased range, better resolution and sharper fish targets.
Axiom 2 Pro models with RealVision MAX feature built-in CHIRP DownVision, SideVision, RealVision 3D and 600-watt traditional CHIRP fishfinder for coastal fishing, plus a 1kW dual channel CHIRP fishfinder for deep water.
One Display- Endless Possibilities
Discover More
Created from official hydrographic chart sources, you can trust LightHouse Charts for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 Pro turn night into day, keeping you safe and secure so you can boat with confidence.
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 Pro on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 Pro on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 Pro with third-party apps from our marine technology partners.
Create a Powerful Navigation System
Two RayNet Ethernet ports and NMEA2000 give you the flexibility to create an Axiom 2 Pro system with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Connections
Ethernet connection
2 RayNet (10/100/1,000 Mbits/s) ports
NMEA 2000 connection
DeviceNet connector
Wi-Fi
Multiband - 2.4GHz, and 5Ghz 802.11b/g/n
Bluetooth
v4.0
Accessory connection
USB Micro B
Internal storage
64GB Solid State
External storage
2 front mounted MicroSDXC card slots
Digital Video and Audio
HDMI Out Micro connector type D
Analog video connections
BNC Analog video input (on power cable)
Analog audio connections
RCA connectors via power cable
External GPS anternna
TNC connector
Physical
Dimensions (Trunnion mounted)
Axiom 2 Pro 16: Height: 281.20 mm (11.10 in), Width 482.50 mm (19.00 in), Depth (including cables): 233.4 mm (9.18 in)
Dimensions (Surface/Flush mounted)
Axiom 2 Pro 16: Height: 258 mm (10.16 in), Width: 452.02 mm (17.8 in), Depth (including cables): 240.4 mm (9.46 in)
Power
Power consumption @ 12 V dc
Axiom Pro 16: 42.36 W
Power consumption @ 24 V dc
Axiom Pro 16: 40.8 W
Operating voltage range
8 V dc to 32 V dc
Nominal supply voltage
12 V dc / 24 V dc
Off current @ 12 V dc
11 mA (0.13 W)
Off current @ 24 V dc
18 mA (0.43 W)
LEN (NMEA 2000 Load Equivalency Number)
1
Current
5 A
Fuse rating
15 A
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70°C (-22 Degree F to 158 Degree F)
Relative humidity
Up to 93% @ 40 Degree C (104°F)
Waterproof rating
IPx6, IPx7
LC
Size (diagonal)
Axiom 2 Pro 16: 15.6"
Ratio
Axiom 2 Pro 16: 16:10
Resolution
Axiom 2 Pro 16: 1920 x 1080 FHD
Viewing angle
Top 88° / Bottom 88° / Left 88° / Right 88°
Type
IPS (In-Plane Switching)
Color depth
24-bit
Illumination
Axiom 2 Pro 16 1200 nits / 1200 cd/m2
Number of simultaneous touches
1 to 16
GPS (GNSS)
Position Accuracy
Without SBAS: ≤ 15 metres 95% of the time, With SBAS: ≤ 5 metres 95% of the time
Geodetic Datum
WGS-84 (alternatives can be selected on the MFD)
Satellite Differential Type (SBAS)
WAAS (United States), EGNOS (Europe), MSAS (Japan), GAGAN (India), QZSS (Japan)
Channels
Track up to 28 satellites simultaneously
Antenna
Internal - Ceramic chip mounted near top of unit
GNSS compatibility
GPS, Galileo, GLONASS, Beidou
Almanac Update
Automatic
Signal Acquisition
Automatic
Receiver IC Sensitivity
165 dBm (Tracking), 160 dBm (Acquisition), 148 dBm (Cold start)
Operating frequency
1574 MHz to 1605 MHz
Refresh rate
10 Hz (10 times per second)
Time to first fix from cold start
< 2 minutes
Sonar
Power output
RealVision MAX high CHIRP sonar channel: 600 Watts RMS
Traditional dual channel CHIRP channel: 1kW RMS
Sonar channels
RealVision MAX Port: High CHIRP (200kHz), DownVision (350kHz), SideVision (350kHz) and RealVision 3D (350kHz)
1kW CHIRP Port: 42 - 250kHz (Transducer dependent)
RealVision MAX Depth range
25-pin RealVision type connector: High CHIRP conical sonar: 366 m (1200 ft), DownVision: 183 m (600 ft), SideVision: 91 m (300 ft), RealVision 3D: 91 m (300 ft)
1 kW Depth range
11 pin 1kW connector: : 0.9 m (3 ft) to 914.4 m (3,000 ft) (In optimum conditions using a 1kW transducer)
Connections
1x 25-pin RealVision Max 3D / RealVision 3D transducer connector, and 1 x 11-pin 1kW transducer connector
INCLUDED :
Display unit
User Configurable Keypad
Suncover
Gasket
Trunnion knobs (x 2)
Trunnion bracket (Axiom 2 Pro 9 and 12 Only)
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Mounting fixings x4
Documentation
Power/Video/Audio cable 1.5 m (4.92 ft)
Also you can check product : Raymarine Axiom 2 Pro S 16" Chartplotter/Fishfinders with Lighthouse Chart NEW
Your Offshore Adventure Guide
No matter where the day takes you, you’ll be able to handle the unexpected in stride thanks to superior awareness at every turn.
Axiom 2 Pro combines chartplotter, fish finder, radar, autopilot and video into a powerful all-in-one fishing system. Plan your next offshore adventure and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Designed for discovering the deep, Axiom 2 Pro RVM chartplotters feature an integrated multi-channel fish finder with RealVision® MAX CHIRP sonar technology.
Power That Pushes the Limits
Get underway quickly with Axiom 2 Pro’s powerful 6-core processor. Enjoy faster, seamless integration of GPS, fishfinder, radar and video thanks to the super intuitive LightHouse operating system.
Ready for All Conditions
Axiom 2 Pro's HydroTough nano-coating technology repels water for reliable touchscreen control, enhanced colors and excellent sunlight visibility.
Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening lighting conditions.
Confident Control
Plan and plot your course with HybridTouch control and take command with reliable keypad control when seas are rough.
Customize your Axiom 2 Pro with interchangeable keypads that allow you to choose between a dedicated Evolution autopilot keypad or user-programable soft keys.
Find More Fish with RealVision MAX
RealVision MAX ups your fishfinding game with increased range, better resolution and sharper fish targets.
Axiom 2 Pro models with RealVision MAX feature built-in CHIRP DownVision, SideVision, RealVision 3D and 600-watt traditional CHIRP fishfinder for coastal fishing, plus a 1kW dual channel CHIRP fishfinder for deep water.
One Display- Endless Possibilities
Discover More
Created from official hydrographic chart sources, you can trust LightHouse Charts for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 Pro turn night into day, keeping you safe and secure so you can boat with confidence.
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 Pro on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 Pro on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 Pro with third-party apps from our marine technology partners.
Create a Powerful Navigation System
Two RayNet Ethernet ports and NMEA2000 give you the flexibility to create an Axiom 2 Pro system with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Connections
Ethernet connection
2 RayNet (10/100/1,000 Mbits/s) ports
NMEA 2000 connection
DeviceNet connector
Wi-Fi
Multiband - 2.4GHz, and 5Ghz 802.11b/g/n
Bluetooth
v4.0
Accessory connection
USB Micro B
Internal storage
64GB Solid State
External storage
2 front mounted MicroSDXC card slots
Digital Video and Audio
HDMI Out Micro connector type D
Analog video connections
BNC Analog video input (on power cable)
Analog audio connections
RCA connectors via power cable
External GPS anternna
TNC connector
Physical
Dimensions (Trunnion mounted)
Axiom 2 Pro 16: Height: 281.20 mm (11.10 in), Width 482.50 mm (19.00 in), Depth (including cables): 233.4 mm (9.18 in)
Dimensions (Surface/Flush mounted)
Axiom 2 Pro 16: Height: 258 mm (10.16 in), Width: 452.02 mm (17.8 in), Depth (including cables): 240.4 mm (9.46 in)
Power
Power consumption @ 12 V dc
Axiom Pro 16: 42.36 W
Power consumption @ 24 V dc
Axiom Pro 16: 40.8 W
Operating voltage range
8 V dc to 32 V dc
Nominal supply voltage
12 V dc / 24 V dc
Off current @ 12 V dc
11 mA (0.13 W)
Off current @ 24 V dc
18 mA (0.43 W)
LEN (NMEA 2000 Load Equivalency Number)
1
Current
5 A
Fuse rating
15 A
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70°C (-22 Degree F to 158 Degree F)
Relative humidity
Up to 93% @ 40 Degree C (104°F)
Waterproof rating
IPx6, IPx7
LC
Size (diagonal)
Axiom 2 Pro 16: 15.6"
Ratio
Axiom 2 Pro 16: 16:10
Resolution
Axiom 2 Pro 16: 1920 x 1080 FHD
Viewing angle
Top 88° / Bottom 88° / Left 88° / Right 88°
Type
IPS (In-Plane Switching)
Color depth
24-bit
Illumination
Axiom 2 Pro 16 1200 nits / 1200 cd/m2
Number of simultaneous touches
1 to 16
GPS (GNSS)
Position Accuracy
Without SBAS: ≤ 15 metres 95% of the time, With SBAS: ≤ 5 metres 95% of the time
Geodetic Datum
WGS-84 (alternatives can be selected on the MFD)
Satellite Differential Type (SBAS)
WAAS (United States), EGNOS (Europe), MSAS (Japan), GAGAN (India), QZSS (Japan)
Channels
Track up to 28 satellites simultaneously
Antenna
Internal - Ceramic chip mounted near top of unit
GNSS compatibility
GPS, Galileo, GLONASS, Beidou
Almanac Update
Automatic
Signal Acquisition
Automatic
Receiver IC Sensitivity
165 dBm (Tracking), 160 dBm (Acquisition), 148 dBm (Cold start)
Operating frequency
1574 MHz to 1605 MHz
Refresh rate
10 Hz (10 times per second)
Time to first fix from cold start
< 2 minutes
Sonar
Power output
RealVision MAX high CHIRP sonar channel: 600 Watts RMS
Traditional dual channel CHIRP channel: 1kW RMS
Sonar channels
RealVision MAX Port: High CHIRP (200kHz), DownVision (350kHz), SideVision (350kHz) and RealVision 3D (350kHz)
1kW CHIRP Port: 42 - 250kHz (Transducer dependent)
RealVision MAX Depth range
25-pin RealVision type connector: High CHIRP conical sonar: 366 m (1200 ft), DownVision: 183 m (600 ft), SideVision: 91 m (300 ft), RealVision 3D: 91 m (300 ft)
1 kW Depth range
11 pin 1kW connector: : 0.9 m (3 ft) to 914.4 m (3,000 ft) (In optimum conditions using a 1kW transducer)
Connections
1x 25-pin RealVision Max 3D / RealVision 3D transducer connector, and 1 x 11-pin 1kW transducer connector
INCLUDED :
Display unit
User Configurable Keypad
Suncover
Gasket
Trunnion knobs (x 2)
Trunnion bracket (Axiom 2 Pro 9 and 12 Only)
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Mounting fixings x4
Documentation
Power/Video/Audio cable 1.5 m (4.92 ft)
Also you can check product : Raymarine Axiom 2 Pro S 16" Chartplotter/Fishfinders with Lighthouse Chart NEW
Axiom 2 Pro combines chartplotter, fish finder, radar, autopilot and video into a powerful all-in-one fishing system. Plan your next offshore adventure and get underway confidently with Axiom 2 Pro’s HybridTouch-a simple touchscreen and keypad experience made possible by the intuitive LightHouse operating system. Designed for discovering the deep, Axiom 2 Pro RVM chartplotters feature an integrated multi-channel fish finder with RealVision MAX CHIRP sonar technology. Enjoy faster, seamless integration of GPS, fishfinder, radar and video thanks to the super intuitive LightHouse operating system.
Raymarine Axiom 2 XL 24" Premium Glass Bridge Chartplotters NEW (Axiom 2 XL)
Raymarine Axiom 2 XL 24" Premium Glass Bridge Chartplotters NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Power that Pushes the Limits
Axiom 2 XL chartplotters do everything faster. Pan and zoom charts with ease and harness the full power of Axiom 2 XL with radar, sonar modules, autopilot, and video integrated seamlessly with the intelligent LightHouse operating system.
6 Core Processor
Get underway and do everything faster
Ample Storage
64 GB for waypoints, apps, and LightHouse Charts
Axiom 2 XL Faster Performance
Smooth Video and Faster Charts
Faster video frame rates and 30% faster chart rendering
Ready for All Conditions
Axiom 2 XL's exclusive HydroTough nano-coating technology repels water for confident touchscreen control, beautiful colors, and excellent sunlight visibility.
Smart Backlighting
Axiom 2 XL's ambient light sensor automatically adjusts display brightness for day and evening lighting conditions.
Remote Control
Navigate effortlessly with Axiom 2 XL's touchscreen or take command with the optional RMK-10 remote keypad. The RMK-10 provides full remote control of every Axiom on the helm.
One Display- Endless Possibilities
Discover More
Created from official hydrographic charts, you can trust LightHouse Charts and Axiom 2 XL for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 XL turn night into day, keeping you safe and secure so you can boat with confidence.
Fish to the Max
Outfit Axiom 2 XL with CHIRP sonar modules. Choose the CP570 for deep water adventures or the RVM1600 with RealVision MAX SideVision, DownVision, and 3D fish finder.
Advanced Sailing Tools
Axiom 2 XL offers a suite of smart sailing features to help you optimize your performance under sail, including layline overlays, preloaded polars, sailing dashboards, and race timers.
Navigate with Confidence
Axiom 2 XL's intuitive LightHouse operating system makes everything easier. Integrate all navigation, engine and sensor data on a single display
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 XL on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 XL on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 XL with third-party apps from our marine technology partners.
Unleash the Power of Axiom 2 XL
Three RayNet Ethernet POE ports, NMEA2000, HDMI input, HDMI Output, USB, and remote keypad options give you the power to design an Axiom 2 XL glass bridge with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions
Axiom 2 XL 24: Height: 386.84 mm (15.23 in), Width, 578.40 mm (22.77 in), Depth (including cables): 177.39 mm (6.98 in)
Weight
Axiom XL 24: 11.3 kg (24.9 lbs)
USB connection
USB-A: Touch input, USB-B: Touch output
Accessory connection
USB Micro B
GPS antenna connection
TNC type connector
External storage
Remote card reader required
Ethernet connection
PoE RayNet (10/100/1,000 Mbits/s) x 3
HDMI connections
HDMI in, HDMI out
Audio output
Left and Right RCA connectors via Power/Video/Audio cable.
Analog video connections
Composite BNC connectors x 2 (Alarm/Video 1 connector, Power/Data/Video cable Video 2)
NMEA 0183 Support
Via NMEA2000 using NMEA 0183 to NMEA 2000 convertor (part number A80721)
NMEA 2000 connection
DeviceNet connector
Wireless connections
Bluetooth: V4.0, Wi-Fi: Dual band (2.4 GHz and 5 GHz) 802.11/b/g/n
External alarm connection
Bare-ended wires x 2
Internal storage
64 GB Solid State
Power
Power consumption @ 12 V dc
Axiom 2 XL 24: 92.5 W
Power consumption @ 24 V dc
Axiom 2 XL 24: 77.96 W
Off current @ 12 V dc
PoE: 2,135 mA (25.62 W), No PoE: 352 mA (4.32 W)
Off current @ 24 V dc
PoE: 1,161 mA (27.6 W), No PoE: 352 mA (5.54 W)
PoE operating voltage range
9.5 V dc to 32 V dc
Current
Axiom 2 XL 24: 10.03 A
Operating voltage range
8 V dc to 32 V dc
Fuse rating
15 A
Nominal supply voltage
12 V dc / 24 V dc
LEN (NMEA 2000 Load Equivalency Number)
1
LCD
Resolution
Axiom 2 XL 24: 1920 x 1200 WUXGA
Size (diagonal)
Axiom 2 XL 24: 24"
Illumination
Axiom XL 24: 1300 nits / 1300 cd/m2
Viewing angle
Axiom 2 XL 24: Top 89° / Bottom 89° / Left 89° / Right 89°
Ratio
Axiom 2 XL 24: 16:10
Type
IPS (In-Plane Switching)
Color depth
24-bit
Number of simultaneous touches
2
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70 Degree C (-22 Degree F to 158 Degree F)
Relative humidity
up to 93% @ 40 Degree C (104 Degree F)
Waterproof rating
IPx6, IPx7
INCLUDED :
Card Reader
Mounting gasket tape
Rear mounting bars x 2
Mounting bar fixings (M5x20 pozi countersunk) x 4
Mounting fixings: Bolts (M5x35), Wavy washers (M5), Nuts (M5) Mounting feet x 4
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
Documentation
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Power/Video/Audio cable 1.5 m (4.92 ft) right-angled
Also you can check product : Raymarine Axiom 2 XL 22" Premium Glass Bridge Chartplotters NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Raymarine Axiom 2 XL 16" Premium Glass Bridge Chartplotters NEW (Axiom 2 XL)
Raymarine Axiom 2 XL 16" Premium Glass Bridge Chartplotters NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Power that Pushes the Limits
Axiom 2 XL chartplotters do everything faster. Pan and zoom charts with ease and harness the full power of Axiom 2 XL with radar, sonar modules, autopilot, and video integrated seamlessly with the intelligent LightHouse operating system.
6 Core Processor
Get underway and do everything faster
Ample Storage
64 GB for waypoints, apps, and LightHouse Charts
Axiom 2 XL Faster Performance
Smooth Video and Faster Charts
Faster video frame rates and 30% faster chart rendering
Ready for All Conditions
Axiom 2 XL's exclusive HydroTough nano-coating technology repels water for confident touchscreen control, beautiful colors, and excellent sunlight visibility.
Smart Backlighting
Axiom 2 XL's ambient light sensor automatically adjusts display brightness for day and evening lighting conditions.
Remote Control
Navigate effortlessly with Axiom 2 XL's touchscreen or take command with the optional RMK-10 remote keypad. The RMK-10 provides full remote control of every Axiom on the helm.
One Display- Endless Possibilities
Discover More
Created from official hydrographic charts, you can trust LightHouse Charts and Axiom 2 XL for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 XL turn night into day, keeping you safe and secure so you can boat with confidence.
Fish to the Max
Outfit Axiom 2 XL with CHIRP sonar modules. Choose the CP570 for deep water adventures or the RVM1600 with RealVision MAX SideVision, DownVision, and 3D fish finder.
Advanced Sailing Tools
Axiom 2 XL offers a suite of smart sailing features to help you optimize your performance under sail, including layline overlays, preloaded polars, sailing dashboards, and race timers.
Navigate with Confidence
Axiom 2 XL's intuitive LightHouse operating system makes everything easier. Integrate all navigation, engine and sensor data on a single display
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 XL on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 XL on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 XL with third-party apps from our marine technology partners.
Unleash the Power of Axiom 2 XL
Three RayNet Ethernet POE ports, NMEA2000, HDMI input, HDMI Output, USB, and remote keypad options give you the power to design an Axiom 2 XL glass bridge with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions
Axiom 2 XL 16: Height: 248.22 mm (9.77 in), Width, 394.9 mm (15.55 in), Depth (including cables): 174.95 mm (6.89 in)
Weight
Axiom XL 16: 5.9 kg (13 lbs)
USB connection
USB-A: Touch input, USB-B: Touch output
Accessory connection
USB Micro B
GPS antenna connection
TNC type connector
External storage
Remote card reader required
Ethernet connection
PoE RayNet (10/100/1,000 Mbits/s) x 3
HDMI connections
HDMI in, HDMI out
Audio output
Left and Right RCA connectors via Power/Video/Audio cable.
Analog video connections
Composite BNC connectors x 2 (Alarm/Video 1 connector, Power/Data/Video cable Video 2)
NMEA 0183 Support
Via NMEA2000 using NMEA 0183 to NMEA 2000 convertor (part number A80721)
NMEA 2000 connection
DeviceNet connector
Wireless connections
Bluetooth: V4.0, Wi-Fi: Dual band (2.4 GHz and 5 GHz) 802.11/b/g/n
External alarm connection
Bare-ended wires x 2
Internal storage
64 GB Solid State
Power
Power consumption @ 12 V dc
Axiom 2 XL 16: 76.56 W
Power consumption @ 24 V dc
Axiom 2 XL 16: 71.53 W
Off current @ 12 V dc
PoE: 2,135 mA (25.62 W), No PoE: 352 mA (4.32 W)
Off current @ 24 V dc
PoE: 1,161 mA (27.6 W), No PoE: 352 mA (5.54 W)
PoE operating voltage range
9.5 V dc to 32 V dc
Current
Axiom 2 XL 16: 8.56 A
Operating voltage range
8 V dc to 32 V dc
Fuse rating
15 A
Nominal supply voltage
12 V dc / 24 V dc
LEN (NMEA 2000 Load Equivalency Number)
1
LCD
Resolution
Axiom 2 XL 16: 1920 x 1080 pixels
Size (diagonal)
Axiom 2 XL 16: 15.6"
Illumination
Axiom XL 16: 1300 nits / 1300 cd/m2
Viewing angle
Axiom 2 XL 16: Top 88° / Bottom 88° / Left 88° / Right 88°
Ratio
Axiom 2 XL 16: 16:9
Type
IPS (In-Plane Switching)
Color depth
24-bit
Number of simultaneous touches
2
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70 Degree C (-22 Degree F to 158 Degree F)
Relative humidity
up to 93% @ 40 Degree C (104 Degree F)
Waterproof rating
IPx6, IPx7
INCLUDED :
Mounting gasket tape
Rear mounting bars x 2
Mounting bar fixings (M5x20 pozi countersunk) x 4
Mounting fixings: Bolts (M5x35), Wavy washers (M5), Nuts (M5) Mounting feet x 4
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
Documentation
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Power/Video/Audio cable 1.5 m (4.92 ft) right-angled
Also you can check product : Raymarine Axiom 2 Pro RVM 16" Chartplotter/Fishfinders with Lighthouse Chart NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Raymarine Axiom 2 XL 19" Premium Glass Bridge Chartplotters NEW (Axiom 2 XL)
Raymarine Axiom 2 XL 19" Premium Glass Bridge Chartplotters NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Power that Pushes the Limits
Axiom 2 XL chartplotters do everything faster. Pan and zoom charts with ease and harness the full power of Axiom 2 XL with radar, sonar modules, autopilot, and video integrated seamlessly with the intelligent LightHouse operating system.
6 Core Processor
Get underway and do everything faster
Ample Storage
64 GB for waypoints, apps, and LightHouse Charts
Axiom 2 XL Faster Performance
Smooth Video and Faster Charts
Faster video frame rates and 30% faster chart rendering
Ready for All Conditions
Axiom 2 XL's exclusive HydroTough nano-coating technology repels water for confident touchscreen control, beautiful colors, and excellent sunlight visibility.
Smart Backlighting
Axiom 2 XL's ambient light sensor automatically adjusts display brightness for day and evening lighting conditions.
Remote Control
Navigate effortlessly with Axiom 2 XL's touchscreen or take command with the optional RMK-10 remote keypad. The RMK-10 provides full remote control of every Axiom on the helm.
One Display- Endless Possibilities
Discover More
Created from official hydrographic charts, you can trust LightHouse Charts and Axiom 2 XL for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 XL turn night into day, keeping you safe and secure so you can boat with confidence.
Fish to the Max
Outfit Axiom 2 XL with CHIRP sonar modules. Choose the CP570 for deep water adventures or the RVM1600 with RealVision MAX SideVision, DownVision, and 3D fish finder.
Advanced Sailing Tools
Axiom 2 XL offers a suite of smart sailing features to help you optimize your performance under sail, including layline overlays, preloaded polars, sailing dashboards, and race timers.
Navigate with Confidence
Axiom 2 XL's intuitive LightHouse operating system makes everything easier. Integrate all navigation, engine and sensor data on a single display
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 XL on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 XL on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 XL with third-party apps from our marine technology partners.
Unleash the Power of Axiom 2 XL
Three RayNet Ethernet POE ports, NMEA2000, HDMI input, HDMI Output, USB, and remote keypad options give you the power to design an Axiom 2 XL glass bridge with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions
Axiom 2 XL 19: Height: 289.44 mm (11.40 in), Width, 461.78 mm (18.18 in), Depth (including cables): 174.95 mm (6.89 in)
Weight
Axiom XL 19: 7.6 kg (16.76 lbs)
USB connection
USB-A: Touch input, USB-B: Touch output
Accessory connection
USB Micro B
GPS antenna connection
TNC type connector
External storage
Remote card reader required
Ethernet connection
PoE RayNet (10/100/1,000 Mbits/s) x 3
HDMI connections
HDMI in, HDMI out
Audio output
Left and Right RCA connectors via Power/Video/Audio cable.
Analog video connections
Composite BNC connectors x 2 (Alarm/Video 1 connector, Power/Data/Video cable Video 2)
NMEA 0183 Support
Via NMEA2000 using NMEA 0183 to NMEA 2000 convertor (part number A80721)
NMEA 2000 connection
DeviceNet connector
Wireless connections
Bluetooth: V4.0, Wi-Fi: Dual band (2.4 GHz and 5 GHz) 802.11/b/g/n
External alarm connection
Bare-ended wires x 2
Internal storage
64 GB Solid State
Power
Power consumption @ 12 V dc
Axiom 2 XL 19: 85.42 W
Power consumption @ 24 V dc
Axiom 2 XL 19: 73.98 W
Off current @ 12 V dc
PoE: 2,135 mA (25.62 W), No PoE: 352 mA (4.32 W)
Off current @ 24 V dc
PoE: 1,161 mA (27.6 W), No PoE: 352 mA (5.54 W)
PoE operating voltage range
9.5 V dc to 32 V dc
Current
Axiom 2 XL 19: 8.98 A
Operating voltage range
8 V dc to 32 V dc
Fuse rating
15 A
Nominal supply voltage
12 V dc / 24 V dc
LEN (NMEA 2000 Load Equivalency Number)
1
LCD
Resolution
Axiom 2 XL 19: 1920 x 1080 pixels
Size (diagonal)
Axiom 2 XL 19: 18.5"
Illumination
Axiom XL 19: 1200 nits / 1200 cd/m2
Viewing angle
Axiom 2 XL 19: Top 88° / Bottom 88° / Left 88° / Right 88°
Ratio
Axiom 2 XL 19: 16:9
Type
IPS (In-Plane Switching)
Color depth
24-bit
Number of simultaneous touches
2
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70 Degree C (-22 Degree F to 158 Degree F)
Relative humidity
up to 93% @ 40 Degree C (104 Degree F)
Waterproof rating
IPx6, IPx7
INCLUDED :
Mounting gasket tape
Rear mounting bars x 2
Mounting bar fixings (M5x20 pozi countersunk) x 4
Mounting fixings: Bolts (M5x35), Wavy washers (M5), Nuts (M5) Mounting feet x 4
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
Documentation
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Power/Video/Audio cable 1.5 m (4.92 ft) right-angled
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Raymarine Axiom 2 XL 22" Premium Glass Bridge Chartplotters NEW (Axiom 2 XL)
Raymarine Axiom 2 XL 22" Premium Glass Bridge Chartplotters NEW
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Power that Pushes the Limits
Axiom 2 XL chartplotters do everything faster. Pan and zoom charts with ease and harness the full power of Axiom 2 XL with radar, sonar modules, autopilot, and video integrated seamlessly with the intelligent LightHouse operating system.
6 Core Processor
Get underway and do everything faster
Ample Storage
64 GB for waypoints, apps, and LightHouse Charts
Axiom 2 XL Faster Performance
Smooth Video and Faster Charts
Faster video frame rates and 30% faster chart rendering
Ready for All Conditions
Axiom 2 XL's exclusive HydroTough nano-coating technology repels water for confident touchscreen control, beautiful colors, and excellent sunlight visibility.
Smart Backlighting
Axiom 2 XL's ambient light sensor automatically adjusts display brightness for day and evening lighting conditions.
Remote Control
Navigate effortlessly with Axiom 2 XL's touchscreen or take command with the optional RMK-10 remote keypad. The RMK-10 provides full remote control of every Axiom on the helm.
One Display- Endless Possibilities
Discover More
Created from official hydrographic charts, you can trust LightHouse Charts and Axiom 2 XL for maximum readability, intuitive navigation, and superior quality.
Upgrade your Awareness
Add a Quantum 2 radome or Cyclone open array radar and navigate safer with Doppler target tracking and radar/chart overlay.
Turn Night Into Day
FLIR thermal imaging and Axiom 2 XL turn night into day, keeping you safe and secure so you can boat with confidence.
Fish to the Max
Outfit Axiom 2 XL with CHIRP sonar modules. Choose the CP570 for deep water adventures or the RVM1600 with RealVision MAX SideVision, DownVision, and 3D fish finder.
Advanced Sailing Tools
Axiom 2 XL offers a suite of smart sailing features to help you optimize your performance under sail, including layline overlays, preloaded polars, sailing dashboards, and race timers.
Navigate with Confidence
Axiom 2 XL's intuitive LightHouse operating system makes everything easier. Integrate all navigation, engine and sensor data on a single display
Make Smarter Decisions
Add a CAM300 and an AR200 sensor for ClearCruise augmented reality. See AIS, waypoints, and chart objects overlaid on high-definition video.
Advanced Engine Integration
Connect with NMEA2000-compatible engines or experience advanced integration with Mercury SmartCraft and Yamaha Command Link engines.
Stream, Watch, and Listen
Stream Netflix and Spotify, connect and control Fusion, JL Audio, and Rockford Fosgate marine audio systems, or view Axiom 2 XL on the big screen with HDMI output.
Smarter Boating
Stay Connected
Add the YachtSense Link router and keep your system connected onboard and off with the Raymarine mobile App.
Axiom on your Smartphone
Built-in Wi-Fi lets you view and control your Axiom 2 XL on your phone or tablet with the Raymarine Mobile App.
Do More with LightHouse Apps
Expand the capabilities of our Axiom 2 XL with third-party apps from our marine technology partners.
Unleash the Power of Axiom 2 XL
Three RayNet Ethernet POE ports, NMEA2000, HDMI input, HDMI Output, USB, and remote keypad options give you the power to design an Axiom 2 XL glass bridge with multiple Axiom displays, fish finder modules, marine radar, autopilot, thermal, and video cameras.
Specifications :
Physical
Dimensions
Axiom 2 XL 22: Height: 326.33 mm (12.85 in), Width, 533.56 mm (21.00 in), Depth (including cables): 180.75 mm (7.12 in)
Weight
Axiom XL 22: 9.9 kg (21.83 lbs)
USB connection
USB-A: Touch input, USB-B: Touch output
Accessory connection
USB Micro B
GPS antenna connection
TNC type connector
External storage
Remote card reader required
Ethernet connection
PoE RayNet (10/100/1,000 Mbits/s) x 3
HDMI connections
HDMI in, HDMI out
Audio output
Left and Right RCA connectors via Power/Video/Audio cable.
Analog video connections
Composite BNC connectors x 2 (Alarm/Video 1 connector, Power/Data/Video cable Video 2)
NMEA 0183 Support
Via NMEA2000 using NMEA 0183 to NMEA 2000 convertor (part number A80721)
NMEA 2000 connection
DeviceNet connector
Wireless connections
Bluetooth: V4.0, Wi-Fi: Dual band (2.4 GHz and 5 GHz) 802.11/b/g/n
External alarm connection
Bare-ended wires x 2
Internal storage
64 GB Solid State
Power
Power consumption @ 12 V dc
Axiom 2 XL 22: 94.25 W
Power consumption @ 24 V dc
Axiom 2 XL 22: 79.46 W
Off current @ 12 V dc
PoE: 2,135 mA (25.62 W), No PoE: 352 mA (4.32 W)
Off current @ 24 V dc
PoE: 1,161 mA (27.6 W), No PoE: 352 mA (5.54 W)
PoE operating voltage range
9.5 V dc to 32 V dc
Current
Axiom 2 XL 22: 10.12 A
Operating voltage range
8 V dc to 32 V dc
Fuse rating
15 A
Nominal supply voltage
12 V dc / 24 V dc
LEN (NMEA 2000 Load Equivalency Number)
1
LCD
Resolution
Axiom 2 XL 22: 1920 x 1080 pixels
Size (diagonal)
Axiom 2 XL 22: 21.5"
Illumination
Axiom XL 22: 1275 nits / 1275 cd/m2
Viewing angle
Axiom 2 XL 22: Top 89° / Bottom 89° / Left 89° / Right 89°
Ratio
Axiom 2 XL 22: 16:9
Type
IPS (In-Plane Switching)
Color depth
24-bit
Number of simultaneous touches
2
Environmental
Operating temperature
-25 Degree C to 55 Degree C (-13 Degree F to 131 Degree F)
Storage temperature
-30 Degree C to 70 Degree C (-22 Degree F to 158 Degree F)
Relative humidity
up to 93% @ 40 Degree C (104 Degree F)
Waterproof rating
IPx6, IPx7
INCLUDED :
Mounting gasket tape
Rear mounting bars x 2
Mounting bar fixings (M5x20 pozi countersunk) x 4
Mounting fixings: Bolts (M5x35), Wavy washers (M5), Nuts (M5) Mounting feet x 4
Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3))
Documentation
DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft)
RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft)
Power/Video/Audio cable 1.5 m (4.92 ft) right-angled
The flagship of the Axiom family, Axiom 2 XL delivers powerful chartplotter performance, stylish large-format navigation, and the confidence of the LightHouse operating system. Designed for all weather conditions, the rugged yet beautiful Axiom 2 XL displays are at home in open cockpits or enclosed glass bridge stations. Enhanced with powerful 6-core processors, expanded networking, and ultra-bright HydroTough displays, Axiom 2 XL is the premium chartplotter for captains who demand the best.
Garmin GPSMAP 9222 Premium Chartplotter with Garmin Navionics Plus NEW (GPSMAP 9222 )
Garmin GPSMAP 9222 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
17.55 lbs (7.96 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
18.7" x 10.5" x 21.5" diagonal, 47.5 cm x 26.7 cm x 54.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9222 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Raymarine Axiom 2 XL 24" Premium Glass Bridge Chartplotters NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
17.55 lbs (7.96 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
18.7" x 10.5" x 21.5" diagonal, 47.5 cm x 26.7 cm x 54.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9222 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Raymarine Axiom 2 XL 24" Premium Glass Bridge Chartplotters NEW
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look. Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag. routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
Garmin GPSMAP 9224 Premium Chartplotter with Garmin Navionics Plus NEW (GPSMAP 9224)
Garmin GPSMAP 9224 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
22.7" x 14.8" x 2.7" (57.6 cm x 37.6 cm x 6.9 cm)
Weight
20.60 lbs (9.34 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
20.7" x 11.7" x 23.8" diagonal, 52.7 cm x 29.6 cm x 60.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
6.5A
Maximum current draw at 12 Vdc
6.8A
Maximum power usage at 10 Vdc
82W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9224 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9222 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
22.7" x 14.8" x 2.7" (57.6 cm x 37.6 cm x 6.9 cm)
Weight
20.60 lbs (9.34 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
20.7" x 11.7" x 23.8" diagonal, 52.7 cm x 29.6 cm x 60.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
6.5A
Maximum current draw at 12 Vdc
6.8A
Maximum power usage at 10 Vdc
82W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9224 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9222 Premium Chartplotter with Garmin Navionics Plus NEW
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look. Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag. routes2 with lightning speed with an optional Garmin Navionics subscription.
Garmin GPSMAP 9227 Premium Chartplotter with Garmin Navionics Plus NEW (GPSMAP 9227)
Garmin GPSMAP 9227 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
25.8" x 16.7" x 3.3" (65.5 cm x 42.3 cm x 8.5 cm)
Weight
27.65 lbs (12.54 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
23.5" x 13.2" x 27.0" diagonal, 59.7 cm x 33.6 cm x 68.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
7.2A
Maximum current draw at 12 Vdc
8.1A
Maximum power usage at 10 Vdc
97W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9227 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9224 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
25.8" x 16.7" x 3.3" (65.5 cm x 42.3 cm x 8.5 cm)
Weight
27.65 lbs (12.54 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
23.5" x 13.2" x 27.0" diagonal, 59.7 cm x 33.6 cm x 68.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
7.2A
Maximum current draw at 12 Vdc
8.1A
Maximum power usage at 10 Vdc
97W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9227 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9224 Premium Chartplotter with Garmin Navionics Plus NEW
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look. Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag. routes2 with lightning speed with an optional Garmin Navionics subscription.
Garmin 9024 Premium Chartplotter with Worldwide Basemap NEW (9024)
Garmin 9024 Premium Chartplotter with Worldwide Basemap NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
20.60 lbs (9.34 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
20.7" x 11.7" x 23.8" diagonal, 52.7 cm x 29.6 cm x 60.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9024 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin 9022 Premium Chartplotter with Worldwide Basemap NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
20.60 lbs (9.34 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
20.7" x 11.7" x 23.8" diagonal, 52.7 cm x 29.6 cm x 60.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9024 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin 9022 Premium Chartplotter with Worldwide Basemap NEW
Welcome to 4K paradise. As the industry’s first integrated 4K resolution touchscreen chartplotter, the GPSMAP 9000 series is designed for captains who demand the best. Cruisers and anglers can enjoy edge-to-edge clarity on a glass helm with premium design and materials. These premier MFDs feature processing power that is 7 times faster than previous generations, along with comprehensive connectivity throughout your vessel. Enjoy multimedia streaming and seamless video integration. Get a connected boating experience by linking your compatible MFDs, cameras, sonars and more on the new Garmin BlueNet network.
Garmin 9022 Premium Chartplotter with Worldwide Basemap NEW (9022)
Garmin 9022 Premium Chartplotter with Worldwide Basemap NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
17.55 lbs (7.96 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
18.7" x 10.5" x 21.5" diagonal, 47.5 cm x 26.7 cm x 54.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9022 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9227 Premium Chartplotter with Garmin Navionics Plus NEW
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
20.8" x 13.6" x 2.7" (52.9 cm x 34.6 cm x 6.9 cm)
Weight
17.55 lbs (7.96 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
18.7" x 10.5" x 21.5" diagonal, 47.5 cm x 26.7 cm x 54.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
5.2A
Maximum current draw at 12 Vdc
5.7A
Maximum power usage at 10 Vdc
68W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9022 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin GPSMAP 9227 Premium Chartplotter with Garmin Navionics Plus NEW
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look. Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag. routes2 with lightning speed with an optional Garmin Navionics subscription.
Garmin 9027 Premium Chartplotter with Worldwide Basemap NEW (9027)
Garmin 9027 Premium Chartplotter with Worldwide Basemap NEW
Welcome to 4K paradise. As the industry’s first integrated 4K resolution touchscreen chartplotter, the GPSMAP 9000 series is designed for captains who demand the best. Cruisers and anglers can enjoy edge-to-edge clarity on a glass helm with premium design and materials. These premier MFDs feature processing power that is 7 times faster than previous generations, along with comprehensive connectivity throughout your vessel. Enjoy multimedia streaming and seamless video integration. Get a connected boating experience by linking your compatible MFDs, cameras, sonars and more on the new Garmin BlueNet network.
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
25.8" x 16.7" x 3.3" (65.5 cm x 42.3 cm x 8.5 cm)
Weight
27.65 lbs (12.54 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
23.5" x 13.2" x 27.0" diagonal, 59.7 cm x 33.6 cm x 68.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
7.2A
Maximum current draw at 12 Vdc
8.1A
Maximum power usage at 10 Vdc
97W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9027 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin 9024 Premium Chartplotter with Worldwide Basemap NEW
Welcome to 4K paradise. As the industry’s first integrated 4K resolution touchscreen chartplotter, the GPSMAP 9000 series is designed for captains who demand the best. Cruisers and anglers can enjoy edge-to-edge clarity on a glass helm with premium design and materials. These premier MFDs feature processing power that is 7 times faster than previous generations, along with comprehensive connectivity throughout your vessel. Enjoy multimedia streaming and seamless video integration. Get a connected boating experience by linking your compatible MFDs, cameras, sonars and more on the new Garmin BlueNet network.
WELCOME TO 4K PARADISE
It’s the industry’s first integrated 4K resolution touchscreen chartplotter. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials plus enhanced connectivity and speed.
PREMIUM 4K IPS SUNLIGHT-READABLE TOUCHSCREEN DISPLAY
UP TO 7 TIMES FASTER PROCESSING POWER THAN PREVIOUS GENERATIONS
GIGABIT SPEEDS ON THE GARMIN BLUENET™ NETWORK
VIDEO INTEGRATION CAPABILITIES WITH HDCP DISTRIBUTION
SEE SONAR TARGETS LIKE NEVER BEFORE ON THE 4K DISPLAY1
NETWORK WITH MULTIPLE CHARTPLOTTERS, CAMERAS AND SONARS
PREMIUM CHARTPLOTTER
The 4K resolution IPS sunlight-readable touchscreen display is available in the industry’s largest integrated chartplotter size. Edge-to-edge design provides a seamless and luxurious modern look.
FASTER. MUCH FASTER.
Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance ™ routes2 with lightning speed with an optional Garmin Navionics ™ subscription.
GARMIN BLUENET NETWORK
Build extensive networks with multiple chartplotters, cameras, radars and sonars-and enjoy 10 times faster networking speeds with minimal lag.
ENTERTAINMENT OPTIONS
Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.
HIGH-DEFINITION SONAR
Fish in stunning high definition. Hook up to any of our sonar modules, and view sonar targets on the 4K display (transducers sold separately).
CONNECT YOUR ECOSYSTEM
Take command through digital system integrations to monitor, automate and control your vessel. The chartplotter uses the NMEA 2000 and NMEA 0183 networks to connect to your compatible accessories.
Connect
Software Updates-Get wireless software updates via the ActiveCaptain® app with your compatible smartphone or tablet.
Engine Monitoring - Keep tabs on engine performance with extensive engine integration.
Custom Look-Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.
Navigate
Mapping-Navigate with optional Garmin Navionics charts that include Auto Guidance technology, daily updates, and more2 (subscription required)
Premium Charts - Get support for Garmin Navionics Vision charts with premium relief shading and satellite imagery.
Know Where You Are-Get your precise location with the included GPS 24xd position receiver and antenna.
Autopilot-Control the autopilot with any compatible chartplotter on the network with autopilot integration.
Integrate
Connect Cameras-Get extensive camera support and control to see footage directly on the chartplotter.
Surround View System-Get a bird’s-eye view with support for our Surround View Camera System (accessory purchase required).
Control With Your Watch-Connect to your chartplotter with your compatible Garmin smartwatch.
Wireless Connectivity-Connect compatible devices with integrated BLUETOOTH and ANT technologies.
Fish Mapping-Get comprehensive fishing data with the Fish Mapping™ feature from SiriusXM Radio (accessory purchase and subscription required).
Verbal Commands-Use spoken commands to control the chartplotter through your compatible headset.
Weather-Resistant-The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.
Specifications :
General
Dimension
25.8" x 16.7" x 3.3" (65.5 cm x 42.3 cm x 8.5 cm)
Weight
27.65 lbs (12.54 kg)
Water rating
IPX7
Touchscreen
Yes
Display Type
4K, IPS
Display Size
23.5" x 13.2" x 27.0" diagonal, 59.7 cm x 33.6 cm x 68.5 cm diagonal
Display resolution
3840 x 2160 pixels
Mounting Options
Flush or flat
Input
Touchscreen
Maps and Memory
Accepts Data Cards
2 SD Cards
Compatible with Garmin SD card reader
Yes
Waypoints
5000
Track points
50,000
Tracks
50 saved tracks
Navigation Routes
100
Sensors
GPS
Yes
GLONASS
Yes
Galileo
Yes
BeiDou
Yes
Receiver
10 Hz (included receiver)
NMEA 2000 Compatible
Yes
NMEA 0183 Compatible
Yes
Supports WAAS
Yes
Supports multi-band, multi-constellation GPS
Yes
Built-in Maps
Built-in Auto Guidance
Yes
Garmin Navionics Inland & Coastal
Yes
Tide tables
Yes
Optional Map Support
Garmin Navionics
Yes
Garmin Navionics Vision ™
Yes
TOPO 100K
Yes
Garmin Quickdraw Contours
Yes
Raster chart support
Yes
Chartplotter Features
Smart Mode Compatible
Yes
AIS
Yes
DSC
Yes
Supports Fusion-Link compatible radios
Yes
GSD Black Box Sonar Support
Yes
GCV Black Box Sonar Support
Yes
ActiveCaptain compatible
Yes
GRID (Garmin Remote Input Device) compatible
Yes
Wireless Remote Compatible
Yes
Sailing Features
Yes
Spoken audio alerts
Yes
OneHelm support
Yes
Electrical Features
Power Input
10 to 35 Vdc
Typical current draw at 12 Vdc
7.2A
Maximum current draw at 12 Vdc
8.1A
Maximum power usage at 10 Vdc
97W
Sonar Features
Displays sonar
Yes
Traditional sonar (dual frequency/beam)
Yes (with compatible black box sonar)
ClearVü
Yes (with compatible black box sonar)
SideVü
Yes (with compatible black box sonar)
Panoptix sonar
Yes
LiveScope
Yes
Connections
NMEA 2000 ports
1
NMEA 0183 Input (Rx) Ports
1
NMEA 0183 output (Tx) ports
1
Video input ports
1 (BNC composite); 2 HDMI (HDCP compliant)
Video output ports
1 HDMI
J1939 ports
1
Garmin BlueNet network ports
4
USB ports
Yes (2x USB-C)
Bluetooth pairing
Yes
ANT (Connectivity)
Yes
Garmin Wi-Fi network (local connection)
Yes
Audio output
Yes
INCLUDED :
GPSMAP 9027 chartplotter
Trim snap cover
Protective cover
Flush mount hardware
Power cable
GPS 24xd NMEA 2000 (with pole mount, flush mount and under deck mount adapters)
NMEA 2000 backbone/drop cable (2 meters)
NMEA 2000 power cable
NMEA 2000 T-connector and terminator kit
Documentation
Also you can check product : Garmin 9024 Premium Chartplotter with Worldwide Basemap NEW
Welcome to 4K paradise. As the industry’s first integrated 4K resolution touchscreen chartplotter, the GPSMAP 9000 series is designed for captains who demand the best. Cruisers and anglers can enjoy edge-to-edge clarity on a glass helm with premium design and materials. These premier MFDs feature processing power that is 7 times faster than previous generations, along with comprehensive connectivity throughout your vessel. Enjoy multimedia streaming and seamless video integration. Get a connected boating experience by linking your compatible MFDs, cameras, sonars and more on the new Garmin BlueNet network.
Humminbird Apex 19 MSI Plus Chartplotters Included Transducer NEW (Apex 19)
Humminbird Apex 19 MSI Plus Chartplotters Included Transducer NEW
The APEX 19 MSIPLus Chartplotter provides the clearest sonar imaging on the sharpest multi-function display that anglers have ever seen. See it all with a 18.5" Full-HD touchscreen that provides a customized display of information from advanced network options like NMEA 2000, HDMI In/Out, WiFi and Bluetooth. Find your fishing spots faster with included LakeMaster and CoastMaster VX Maps. Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada with confidence. Tools like 1-foot contours and depth and shallow water highlights help you traverse waters with certainty. Industry-leading MEGA Imaging and Dual Spectrum CHIRP sonar come standard, with even more performance from a dedicated sonar channel for accessory 2D CHIRP transducers up to 2kW. Add the power of the One-Boat Network™ to integrate the accuracy of Humminbird GPS charts, unrivaled boat control from Minn Kota, and reach new depths with wireless Cannon Optimum downrigger control. The APEX Series is a new kind of MFD that will take you fishing to a new level.
FEATURES
Full-HD Display with Cross Touch interface
APEX delivers eye-popping detail with a 1920H x 1080V display. See the incredible detail of sonar and chart images that will ensure you never miss a thing. Control it all using the touchscreen or the keypad-it's up to you.
Includes LakeMaster and CoastMaster VX Maps
Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada safely and with confidence. Tools like 1-foot contours, depth and shallow water highlights help you traverse waters with certainty.
Industry-leading Humminbird sonar
Equipped with MEGA Side Imaging Plus, MEGA Down ImagingPLus and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging provides views up to 250' under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.
Customized Experience
Dual sonar ports offer connection with any Humminbird sonar options, as well as a dedicated port for 2D CHIRP transducers up to 2kW. Integrated transducer ID provides fast and simple installation of Airmar transducers.
Internal GPS and Humminbird Basemap
Utilize an intuitive user interface and sidebar menu which provide customizable settings and view combinations to make your fishing experience all your own.
Premium Chart Compatible
Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
AutoChart Live
Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster and CoastMaster products, as well as your choice of compatible Navionics charts.
One-Boat Network Compatible
Create real-time maps of your fishing spots, with access to patented Humminbird LakeMaster features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.
Dual Ethernet Ports
Seamlessly integrate and communicate with Minn Kota motors and Cannon Optimum downriggers to unlock more features and capabilities for anglers everywhere. Make the most of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.
HDMI Compatible
Build a powerful, professional-grade fishing system with dual Ethernet ports on APEX chartplotters. Easily network products without the need for an external network hub, allowing the connection of multiple control heads and Ethernet accessories like Minn Kota Advanced GPS Motors and Humminbird CHIRP Radar.
Bluetooth
See it all with independent HDMI In and HDMI Out ports on APEX. Connect and view accessory camera and video sources, as well as output to accessory displays for more viewing and rigging options.
NMEA 2000 Networking Built-in
Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird One-Boat App.
Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.
Includes control head, Lakemaster and Coastmaster U.S./Canada VX Map Card, screen cover, transom mount transducer, mounting hardware, power cable, and gimbal mounting bracket. Product comes with 2-Year Limited Warranty.
APEX's low-profile design provides a sleek look at the helm when installed with the included front-mount in-dash kit.
In-Dash Installation Note: If indash mounted, an external GPS antenna is required to ensure accurate positioning and navigation.
Compatible with MEGA Live 2 Sonar: Watch fish move, react, and strike your lure with the next-gen clarity of MEGA Live 2 in Forward or Down Mode, now with real-time zoom.
Specifications :
Model
APEX 19 MEGA SI Plus CHARTPLOTTER
Product Code
411240-1VX
Series
APEX
Display Size-Diagonal
18.5 in
Length
11.66 in | 29.62 cm
Height
20.27 in | 51.49 cm
Width
5.33 in | 13.54 cm
Weight
13 lb 8 oz | 6.1235 kg
Display Pixel Matrix
1920H x 1080V
Transducer Included
XM 14 HW MSI T
Compatible With
Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, HDMI In/Out, MEGA Live, AIS, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network, MEGA Live 2
Features
Touch Screen, MEGA Live Imaging, Networking, Down Imaging, Built In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging , Wi-Fi
Memory Card Slot
Dual Micro SD
Sonar-Standard
Dual Spectrum CHIRP, MEGA Side Imaging , MEGA Down Imaging Plus
Sonar-Coverage
20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional
50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low
CHIRP - Frequencies Supported
Narrow Mode (180-240 kHz), Optional Deepwater (28-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported
50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA
Depth-Sonar
3,500 ft (optional Airmar CHIRP), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported
MEGA DI (1100-1200 kHz), 800 kHz SI (780-840 kHz), 455 kHz SI (405-505 kHz), 800 kHz DI (800-860 kHz), MEGA SI (1050-1175 kHz), 455 kHz DI (420-520 kHz)
Depth-Down Imaging
250 ft (MEGA), 400 ft (455 kHz), 125 ft (800 kHz)
Range-Side Imaging (Side-To-Side)
800 ft (455 kHz), 500 ft (MEGA), 250 ft (800 kHz)
Interface
Touch Screen
Power Draw
4.4 Amps
Power Input
10.8-20 VDC
Power Output Peak-to-Peak
8000 Watts
Power Output RMS
1000 Watts
Screen Snap Shot
Included
Sonar Recording
Included
Mount-Standard
Gimbal
Mount-Standard Size
20.27 in W x 12.58 in H x 4.95 in D
Mount-Optional
In-Dash Mounting Kit
Mount-Optional Size
20.27 in W x 11.66 in H x 0.51 in D
Transducer Mount Location
Transom
GPS Chartplotting
Included
GPS Receiver
Internal
GPS Trackplotting
Included
Waypoints, Routes, Tracks/Points
10,000, 50, 50/20,000
360 Imaging Compatibility
Yes
MEGA Live Compatibility
Yes
Humminbird Basemap
Included
LakeMaster Compatibility
Yes
CoastMaster Compatibility
Yes
Navionics Gold/HotMaps Compatibility
Yes
Navionics Platinum Compatibility
Yes
Platinum Compatibility
Yes
Minn Kota Advanced GPS Navigation Compatibility
Yes
Minn Kota i-Pilot Link Compatibility
Yes
Minn Kota Talon Shallow Water Anchor Compatibility
Yes
Radar Compatibility
Yes
5-Port Ethernet Switch Compatibility
Yes
AIS Compatibility
Optional
Autopilot Compatibility
Yes
Heading Sensor GPS Compatibility
Yes
Heading Sensor GPS (NMEA 2000) Compatibility
Yes
NMEA2000
Included
Target Separation
2.5 in
Upgradable Software
Yes
View Preset Keys
Yes
X-Press Menu System
No
Custom Digital Readout
Yes
Custom View Selections
Yes
Display Colors Grayscale
16-Bit
Display Type
Color TFT
Speed
Included
Temperature
Built In
Temperature Alarm
Yes
Temperature Graph
Yes
HDMI Compatible
Yes
Warranty
Two-Year Warranty
INCLUDED :
APEX Control Head
10 ft Power Cable
(1) LakeMaster/CoastMaster Map Card
APEX Mounting Bracket & Mounting Hardware
Premium Silicone Unit Cover
XM 14 HW MSI - Transom Transducer
Also you can check product : Garmin 9027 Premium Chartplotter with Worldwide Basemap NEW
The APEX 19 MSIPLus Chartplotter provides the clearest sonar imaging on the sharpest multi-function display that anglers have ever seen. See it all with a 18.5" Full-HD touchscreen that provides a customized display of information from advanced network options like NMEA 2000, HDMI In/Out, WiFi and Bluetooth. Find your fishing spots faster with included LakeMaster and CoastMaster VX Maps. Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada with confidence. Tools like 1-foot contours and depth and shallow water highlights help you traverse waters with certainty. Industry-leading MEGA Imaging and Dual Spectrum CHIRP sonar come standard, with even more performance from a dedicated sonar channel for accessory 2D CHIRP transducers up to 2kW. Add the power of the One-Boat Network™ to integrate the accuracy of Humminbird GPS charts, unrivaled boat control from Minn Kota, and reach new depths with wireless Cannon Optimum downrigger control. The APEX Series is a new kind of MFD that will take you fishing to a new level.
FEATURES
Full-HD Display with Cross Touch interface
APEX delivers eye-popping detail with a 1920H x 1080V display. See the incredible detail of sonar and chart images that will ensure you never miss a thing. Control it all using the touchscreen or the keypad-it's up to you.
Includes LakeMaster and CoastMaster VX Maps
Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada safely and with confidence. Tools like 1-foot contours, depth and shallow water highlights help you traverse waters with certainty.
Industry-leading Humminbird sonar
Equipped with MEGA Side Imaging Plus, MEGA Down ImagingPLus and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging provides views up to 250' under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.
Customized Experience
Dual sonar ports offer connection with any Humminbird sonar options, as well as a dedicated port for 2D CHIRP transducers up to 2kW. Integrated transducer ID provides fast and simple installation of Airmar transducers.
Internal GPS and Humminbird Basemap
Utilize an intuitive user interface and sidebar menu which provide customizable settings and view combinations to make your fishing experience all your own.
Premium Chart Compatible
Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
AutoChart Live
Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster and CoastMaster products, as well as your choice of compatible Navionics charts.
One-Boat Network Compatible
Create real-time maps of your fishing spots, with access to patented Humminbird LakeMaster features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.
Dual Ethernet Ports
Seamlessly integrate and communicate with Minn Kota motors and Cannon Optimum downriggers to unlock more features and capabilities for anglers everywhere. Make the most of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.
HDMI Compatible
Build a powerful, professional-grade fishing system with dual Ethernet ports on APEX chartplotters. Easily network products without the need for an external network hub, allowing the connection of multiple control heads and Ethernet accessories like Minn Kota Advanced GPS Motors and Humminbird CHIRP Radar.
Bluetooth
See it all with independent HDMI In and HDMI Out ports on APEX. Connect and view accessory camera and video sources, as well as output to accessory displays for more viewing and rigging options.
NMEA 2000 Networking Built-in
Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird One-Boat App.
Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.
Includes control head, Lakemaster and Coastmaster U.S./Canada VX Map Card, screen cover, transom mount transducer, mounting hardware, power cable, and gimbal mounting bracket. Product comes with 2-Year Limited Warranty.
APEX's low-profile design provides a sleek look at the helm when installed with the included front-mount in-dash kit.
In-Dash Installation Note: If indash mounted, an external GPS antenna is required to ensure accurate positioning and navigation.
Compatible with MEGA Live 2 Sonar: Watch fish move, react, and strike your lure with the next-gen clarity of MEGA Live 2 in Forward or Down Mode, now with real-time zoom.
Specifications :
Model
APEX 19 MEGA SI Plus CHARTPLOTTER
Product Code
411240-1VX
Series
APEX
Display Size-Diagonal
18.5 in
Length
11.66 in | 29.62 cm
Height
20.27 in | 51.49 cm
Width
5.33 in | 13.54 cm
Weight
13 lb 8 oz | 6.1235 kg
Display Pixel Matrix
1920H x 1080V
Transducer Included
XM 14 HW MSI T
Compatible With
Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, HDMI In/Out, MEGA Live, AIS, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network, MEGA Live 2
Features
Touch Screen, MEGA Live Imaging, Networking, Down Imaging, Built In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging , Wi-Fi
Memory Card Slot
Dual Micro SD
Sonar-Standard
Dual Spectrum CHIRP, MEGA Side Imaging , MEGA Down Imaging Plus
Sonar-Coverage
20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional
50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low
CHIRP - Frequencies Supported
Narrow Mode (180-240 kHz), Optional Deepwater (28-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported
50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA
Depth-Sonar
3,500 ft (optional Airmar CHIRP), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported
MEGA DI (1100-1200 kHz), 800 kHz SI (780-840 kHz), 455 kHz SI (405-505 kHz), 800 kHz DI (800-860 kHz), MEGA SI (1050-1175 kHz), 455 kHz DI (420-520 kHz)
Depth-Down Imaging
250 ft (MEGA), 400 ft (455 kHz), 125 ft (800 kHz)
Range-Side Imaging (Side-To-Side)
800 ft (455 kHz), 500 ft (MEGA), 250 ft (800 kHz)
Interface
Touch Screen
Power Draw
4.4 Amps
Power Input
10.8-20 VDC
Power Output Peak-to-Peak
8000 Watts
Power Output RMS
1000 Watts
Screen Snap Shot
Included
Sonar Recording
Included
Mount-Standard
Gimbal
Mount-Standard Size
20.27 in W x 12.58 in H x 4.95 in D
Mount-Optional
In-Dash Mounting Kit
Mount-Optional Size
20.27 in W x 11.66 in H x 0.51 in D
Transducer Mount Location
Transom
GPS Chartplotting
Included
GPS Receiver
Internal
GPS Trackplotting
Included
Waypoints, Routes, Tracks/Points
10,000, 50, 50/20,000
360 Imaging Compatibility
Yes
MEGA Live Compatibility
Yes
Humminbird Basemap
Included
LakeMaster Compatibility
Yes
CoastMaster Compatibility
Yes
Navionics Gold/HotMaps Compatibility
Yes
Navionics Platinum Compatibility
Yes
Platinum Compatibility
Yes
Minn Kota Advanced GPS Navigation Compatibility
Yes
Minn Kota i-Pilot Link Compatibility
Yes
Minn Kota Talon Shallow Water Anchor Compatibility
Yes
Radar Compatibility
Yes
5-Port Ethernet Switch Compatibility
Yes
AIS Compatibility
Optional
Autopilot Compatibility
Yes
Heading Sensor GPS Compatibility
Yes
Heading Sensor GPS (NMEA 2000) Compatibility
Yes
NMEA2000
Included
Target Separation
2.5 in
Upgradable Software
Yes
View Preset Keys
Yes
X-Press Menu System
No
Custom Digital Readout
Yes
Custom View Selections
Yes
Display Colors Grayscale
16-Bit
Display Type
Color TFT
Speed
Included
Temperature
Built In
Temperature Alarm
Yes
Temperature Graph
Yes
HDMI Compatible
Yes
Warranty
Two-Year Warranty
INCLUDED :
APEX Control Head
10 ft Power Cable
(1) LakeMaster/CoastMaster Map Card
APEX Mounting Bracket & Mounting Hardware
Premium Silicone Unit Cover
XM 14 HW MSI - Transom Transducer
Also you can check product : Garmin 9027 Premium Chartplotter with Worldwide Basemap NEW
The APEX 19 MSI Plus Chartplotter provides the clearest sonar imaging on the sharpest multi-function display that anglers have ever seen. See it all with a 18.5" Full-HD touchscreen that provides a customized display of information from advanced network options like NMEA 2000, HDMI In/Out, WiFi and Bluetooth. Find your fishing spots faster with included LakeMaster and CoastMaster VX Maps. Tools like 1-foot contours and depth and shallow water highlights help you traverse waters with certainty. Industry-leading MEGA Imaging Plus and Dual Spectrum CHIRP sonar come standard, with even more performance from a dedicated sonar channel for accessory 2D CHIRP transducers up to 2kW.
Furuno TZT24X NavNet TZtouchXL 24 inch ChartPlotter-Fish Finder NEW (TZT24X)
FurunoTZT24X NavNet TZtouchXL 24 inch ChartPlotter-Fish Finder NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 24″ all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm.
The TZT24X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
Features
-TZ MAPS for highly detailed navigation and fishing charts
-Purchase and update charts directly from MFD with an internet connection
-Powerful hexacore processor for rapid response
-Video converter kits stream compatible sonar video data directly to TZtouchXL MFD
TZ MAPS
One of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero’s moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!
BathyVision
One of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That’s 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate “Fishing Charts”!
AI Routing
TZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat’s draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.
Risk Visualizer and AI Avoidance Route
When connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.
Enhanced User Interface for Ease of Use & Customizability
In addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.
Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD.
Specifications :
Display Unit:
Type: Color TFT multi-touch IPS LCD
Screen Size: 24″ Wide
Screen Resolution: FHD 1920 x 1080
Screen Brightness: 900 cd/m2 (typical)
Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder)
Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish
Chart Plotter:
Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only)
Memory Capacity: 30,000 user points, 100,000 points for ship’s tracks, 200 planned routes (500 points per route)
Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required)
Interface:
NMEA200: 1 Port
Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880
Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316
NMEA0183: 1 Serial Output Port
Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA
LAN: 1 Port (1000 BASE-T)
USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device
Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only) Output: 1 port (HDMI 1080p)
AUX I/O: 2 Ports (Event Switch and External Power Switch)
SD Card Slot: 1 Slot (Micro SDXC, rear)
Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max
Environment:
Temperature (IEC60945)-15°C to 55° C
Relative Humidity: 93% or less at 40° C
Waterproofing: IP56
Power: 6.7-3.2A
INCLUDED :
TZT24XL 24" MFD Display Unit
24" Silicone MFD Cover
5M Network Cable
2M Power Cable Assy
Fuse 10A 125V x 2
Display Support Bar x 4
Snap On Screw Cover x 2
Screw M3 x 25 x 8
Screw M4 x 30 x 12
Screw M4 x 20 x 12
Installation Manual
Quick Guide
Mounting Template
Display Cleaning Cloth
Also you can check product : Humminbird APEX 16 MSI Plus Chartplotter Included Transducer NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 24″ all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm.
The TZT24X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
Features
-TZ MAPS for highly detailed navigation and fishing charts
-Purchase and update charts directly from MFD with an internet connection
-Powerful hexacore processor for rapid response
-Video converter kits stream compatible sonar video data directly to TZtouchXL MFD
TZ MAPS
One of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero’s moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!
BathyVision
One of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That’s 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate “Fishing Charts”!
AI Routing
TZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat’s draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.
Risk Visualizer and AI Avoidance Route
When connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.
Enhanced User Interface for Ease of Use & Customizability
In addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.
Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD.
Specifications :
Display Unit:
Type: Color TFT multi-touch IPS LCD
Screen Size: 24″ Wide
Screen Resolution: FHD 1920 x 1080
Screen Brightness: 900 cd/m2 (typical)
Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder)
Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish
Chart Plotter:
Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only)
Memory Capacity: 30,000 user points, 100,000 points for ship’s tracks, 200 planned routes (500 points per route)
Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required)
Interface:
NMEA200: 1 Port
Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880
Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316
NMEA0183: 1 Serial Output Port
Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA
LAN: 1 Port (1000 BASE-T)
USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device
Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only) Output: 1 port (HDMI 1080p)
AUX I/O: 2 Ports (Event Switch and External Power Switch)
SD Card Slot: 1 Slot (Micro SDXC, rear)
Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max
Environment:
Temperature (IEC60945)-15°C to 55° C
Relative Humidity: 93% or less at 40° C
Waterproofing: IP56
Power: 6.7-3.2A
INCLUDED :
TZT24XL 24" MFD Display Unit
24" Silicone MFD Cover
5M Network Cable
2M Power Cable Assy
Fuse 10A 125V x 2
Display Support Bar x 4
Snap On Screw Cover x 2
Screw M3 x 25 x 8
Screw M4 x 30 x 12
Screw M4 x 20 x 12
Installation Manual
Quick Guide
Mounting Template
Display Cleaning Cloth
Also you can check product : Humminbird APEX 16 MSI Plus Chartplotter Included Transducer NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 24″ all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm. The TZT24X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
Furuno TZT22X NavNet TZtouchXL 22 inch ChartPlotter-Fish Finder NEW (TZT22X)
Furuno TZT22X NavNet TZtouchXL 22 inch ChartPlotter-Fish Finder NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 22" all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm.
The TZT22X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
Features
TZ MAPS for highly detailed navigation and fishing charts
Purchase and update charts directly from MFD with an internet connection
Powerful hexacore processor for rapid response
Video converter kits stream compatible sonar video data directly to TZtouchXL MFDs
TZ MAPS
One of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!
BathyVision
One of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!
AI Routing
TZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.
Risk Visualizer & AI Avoidance Route
When connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.
Enhanced User Interface for Ease of Use and Customizability
In addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.
Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD.
Specifications :
Display Unit
Type: Color TFT multi-touch IPS LCD
Screen Size: 21.5" Wide
Screen Resolution: FHD 1920 x 1080
Screen Brightness: 900 cd/m2 (typical)
Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder)
Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish
Chart Plotter
Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only)
Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route)
Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required)
Interface
NMEA200: 1 Port
Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880
Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316
NMEA0183: 1 Serial Output Port
Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA
LAN: 1 Port (1000 BASE-T)
USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device
Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only) Output: 1 port (HDMI 1080p)
AUX I/O: 2 Ports (Event Switch and External Power Switch)
SD Card Slot: 1 Slot (Micro SDXC, rear)
Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max
Environment
Temperature (IEC60945)-15°C to 55° C
Relative Humidity: 93% or less at 40° C
Waterproofing: IP56
Power
5.1-2.5A
INCLUDED :
TZT22XL 22" MFD Display Unit
22" Silicone MFD Cover
5M Network Cable
2M Power Cable Assy
Fuse 10A 125V x 2
Display Support Bar x 4
Snap On Screw Cover x 2
Screw M3 x 25 x 8
Screw M4 x 30 x 12
Screw M4 x 20 x 12
Installation Manual
Quick Guide
Mounting Template
Display Cleaning Cloth
Also you can check product : Furuno TZT24X NavNet TZtouchXL 24 inch ChartPlotter-Fish Finder NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 22" all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm.
The TZT22X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
Features
TZ MAPS for highly detailed navigation and fishing charts
Purchase and update charts directly from MFD with an internet connection
Powerful hexacore processor for rapid response
Video converter kits stream compatible sonar video data directly to TZtouchXL MFDs
TZ MAPS
One of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!
BathyVision
One of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!
AI Routing
TZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.
Risk Visualizer & AI Avoidance Route
When connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.
Enhanced User Interface for Ease of Use and Customizability
In addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.
Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD.
Specifications :
Display Unit
Type: Color TFT multi-touch IPS LCD
Screen Size: 21.5" Wide
Screen Resolution: FHD 1920 x 1080
Screen Brightness: 900 cd/m2 (typical)
Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder)
Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish
Chart Plotter
Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only)
Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route)
Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required)
Interface
NMEA200: 1 Port
Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880
Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316
NMEA0183: 1 Serial Output Port
Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA
LAN: 1 Port (1000 BASE-T)
USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device
Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only) Output: 1 port (HDMI 1080p)
AUX I/O: 2 Ports (Event Switch and External Power Switch)
SD Card Slot: 1 Slot (Micro SDXC, rear)
Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max
Environment
Temperature (IEC60945)-15°C to 55° C
Relative Humidity: 93% or less at 40° C
Waterproofing: IP56
Power
5.1-2.5A
INCLUDED :
TZT22XL 22" MFD Display Unit
22" Silicone MFD Cover
5M Network Cable
2M Power Cable Assy
Fuse 10A 125V x 2
Display Support Bar x 4
Snap On Screw Cover x 2
Screw M3 x 25 x 8
Screw M4 x 30 x 12
Screw M4 x 20 x 12
Installation Manual
Quick Guide
Mounting Template
Display Cleaning Cloth
Also you can check product : Furuno TZT24X NavNet TZtouchXL 24 inch ChartPlotter-Fish Finder NEW
NavNet TZtouchXL is the perfect solution for boating enthusiasts who love fishing or cruising. This extra-large, wide 22" all-glass MFD has exceptional clarity from all angles that enhances the functionality and style of a helm. The TZT22X delivers all the features that make the NavNet TZtouch3 a breeze to operate, users can split these large screens into six different windows. The edge-swipe feature makes finding what a user is looking for simple and intuitive. A single tap selects most options, so users are never more than a swipe and tap away from the most accessed features.
